Zebra GX42-202412-000
| Brand | Zebra 2013 |
| Model | GX42-202412-000 |
| Released Year | 2013 |
| Type | Printers |
| Series | GX420 |
| Item Weight | 5.4 pounds |
| Product Dimensions | 11.89 x 10.39 x 8.39 inches |
| Status | Discontinued |
Quick view
Overview
The Zebra GX42-202412-000 is a compact, direct thermal printer designed primarily for label and receipt printing in office and retail environments. It supports printing widths up to 4.09 inches with a maximum print speed of 4 inches per second, making it efficient for medium-volume tasks. The device utilizes a print resolution of 203 dpi that ensures clear text and graphics. It incorporates a durable printhead rated for high reliability under constant use. Connectivity options typically include USB and serial ports, providing flexible integration with various systems. Its compact footprint and metal construction make it robust yet space-efficient for desktop use.
Specifications
| Printer Type | Direct Thermal Desktop Printer |
| Print Width | Up to 4.09 inches (104 mm) |
| Print Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 4 inches per second (102 mm/s) |
| Connectivity | USB 2.0, RS-232 Serial |
| Media Types Supported | Continuous, die-cut, black mark, tags, receipts |
| Media Width | 0.75 inches to 4.3 inches (19 mm to 110 mm) |
| Media Thickness | 2.3 mil to 5.5 mil |
| Printhead | Thermal printhead with high durability |
| Memory | 8 MB SDRAM, 4 MB Flash |
| Dimensions (WxDxH) | 6.9 x 7.5 x 5.9 inches (175 x 191 x 150 mm) |
| Weight | Approximately 3.6 lbs (1.63 kg) |
| Operating Temperature | 40°F to 105°F (5°C to 40°C) |
| Power Supply | External power supply included |
| Font Support | Five resident scalable fonts |
| Emulations | ZPL, EPL, CPCL (depending on firmware) |
| Status Indicators | LED status indicators for power and error |
| Supported Operating Systems | Windows, Linux, Mac OS (drivers available) |
| Print media | Labels |
| Max Input Sheet Capacity | 500 |
| Compatible Devices | PC |
| Sheet Size | 4.25 inches |
| Maximum Black and White Print Resolution | 203 dpi |
| Warranty Type | limited warranty |
| Dual-sided printing | No |
| Max copy resolution black-white | 203 dpi |
| Duplex | Simplex |
| Hardware Interface | USB |
| Additional Printer functions | Print Only |
| Total Ethernet Ports | 1 |
| Total USB Ports | 1 |
| Memory Storage Capacity | 8 MB |
| Manufacturer | ZEBRA |
| Item Weight | 5.4 pounds |
| Product Dimensions | 11.89 x 10.39 x 8.39 inches |
| Item model number | GX42-202412-000 |
| Is Discontinued By Manufacturer | No |
| Manufacturer Part Number | GX42-202412-000 |
| Date First Available | October 1, 2013 |
Images
Key Advantages
The Zebra GX42-202412-000 delivers reliability through a rugged design and consistent print quality. Its direct thermal technology eliminates the need for ink or toner, reducing operational costs and downtime. The compact design is ideal for environments with limited space while maintaining high performance. It supports versatile media handling, accommodating various label sizes and types. The printer is user-friendly with easy media loading and intuitive operation. Additionally, strong connectivity options allow easy system integration for diverse office applications.
Limitations
One notable limitation of the Zebra GX42-202412-000 is its reliance on direct thermal printing which is sensitive to heat and light, leading to label fading over time. The 203 dpi resolution may not be suitable for applications requiring high-definition graphics. Its print speed, while sufficient for medium tasks, is slower compared to some newer models. The device does not inherently support wireless connectivity, limiting modern network flexibility. The maximum label width of just over 4 inches restricts use with larger format media. Also, this model lacks some advanced features found in more recent printers, such as color printing or touchscreen interfaces.
FAQ
What type of printing technology does the Zebra GX42-202412-000 use?
The Zebra GX42-202412-000 uses direct thermal printing technology, which prints by applying heat to thermal-sensitive paper without ink or toner.
Is the Zebra GX42-202412-000 still supported by Zebra?
No, this model has been discontinued, and official support from Zebra has ended.
What are the connectivity options for this printer?
The printer commonly supports USB and RS-232 serial interfaces; wireless support is not included in this model.
What media widths does this printer support?
It supports a maximum print width of approximately 4.09 inches (104 mm).
What is the print resolution of the GX42-202412-000?
It offers a print resolution of 203 dots per inch (dpi).
Can this printer handle color printing?
No, the Zebra GX42-202412-000 supports only monochrome direct thermal printing.
What is the maximum print speed of the Zebra GX42-202412-000?
The maximum print speed of this printer is up to 4 inches per second.
