Zebra 170XiIII Plus image

Zebra 170XiIII Plus

Quick information
Brand Zebra 2008
Model 170-701-00000, 170Xi3, 305 dpi
Released Year 2008
Type Printers
Series Z
Status Discontinued
Quick view
Full specs Images

Overview

The Zebra 170XiIII Plus is an industrial thermal transfer and direct thermal printer engineered for high-volume printing environments. It features a robust metal frame and precision stepper motors that ensure reliable and consistent label printing. The printer supports a 305 dpi resolution, delivering sharp and detailed barcode and text output, suitable for demanding labeling applications. Connectivity options include parallel, serial, and USB interfaces for flexible integration into existing workflows. The device supports a wide range of media types and widths up to 8.5 inches, enhancing versatility across industries. Advanced thermal transfer ribbons compatibility enables longer printhead life and superior print quality.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 8 MB DRAM, 4 MB Flash
MPN 170-701-00000, 170Xi3, 305 dpi
Max. Resolution 300 dpi
Supported Paper Size Max. width: 7,1 in
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Printer Type Label Printer
Technology Thermal
Maximum Resolution 300 x 300 DPI
Model 170XiIII Plus
Connectivity Parallel, Serial RS-232, USB
Black Print Speed 12 ips
Country/Region of Manufacture United States
Product Line Zebra Z
UPC Does not apply
Print Method Thermal Transfer / Direct Thermal
Print Resolution 305 dpi (12 dots/mm)
Print Width up to 8.5 inches (216 mm)
Print Speed up to 6 inches per second
Media Type Labels, Tag stock, Continuous media
Media Handling Adjustable for variable label widths, ribbon rewind/unwind
Processor 32-bit RISC CPU
Dimensions (WxHxD) 14.3 x 15 x 19.3 inches (363 x 381 x 490 mm)
Weight Approximately 40 lbs (18.1 kg)
Operating Temperature 5°C to 40°C (41°F to 104°F)
Power Supply Internal power supply, 90-264 VAC, 47-63 Hz

Key Advantages

The 170XiIII Plus offers industrial-grade durability with a rigid metal chassis designed to withstand harsh environments. Its 305 dpi print resolution ensures exceptional print clarity for barcodes and small fonts. The printer provides high-speed printing, boosting productivity in large-scale operations. Multiple connectivity options simplify integration with various computer systems and networks. It supports a wide range of media types and sizes, increasing application flexibility. Additionally, easy ribbon loading and user-friendly controls streamline operation and maintenance.

Limitations

The Zebra 170XiIII Plus is relatively heavy and bulky, limiting portability in tight workspaces. It consumes more power compared to compact desktop printers. Its ribbon and media handling mechanisms may require periodic calibration to maintain consistent print quality. The device lacks touchscreen interface, relying on manual controls which can be less intuitive. It has a higher initial cost compared to smaller printers, impacting budget considerations. Software compatibility may be limited with some newer operating systems without updated drivers.

FAQ

The Zebra 170XiIII Plus uses thermal transfer and direct thermal printing technologies.

It supports a maximum printing resolution of 305 dots per inch (dpi).

The printer supports media widths up to 8.5 inches (approximately 216 mm).

No, the 170XiIII Plus has been discontinued but some parts and support may still be available.

It offers parallel, serial, and USB connectivity interfaces.

Yes, it can print on a wide variety of media types including labels and tags.

It's commonly used in manufacturing, logistics, warehousing, and retail for barcode labeling and product identification.
