Zebra 140XiIII Plus
Brand | Zebra 2007 |
Model | 140-701-00000, LAN Network, Barcode |
Released Year | 2007 |
Type | Printers |
Series | Xi |
Status | Discontinued |
Quick view
Overview
The Zebra 140XiIII Plus is an industrial thermal transfer barcode printer designed for high-volume, high-quality printing applications. It supports resolutions of 203, 300, and 600 dpi, enabling sharp, precise barcode and text output suitable for various labeling needs. The printer is built with a rugged die-cast print mechanism and a heavy-duty steel frame to ensure durability in demanding industrial environments. It features a large 8-inch OD media capacity and supports continuous, die-cut, black-mark, and fanfold media types. LAN network connectivity allows seamless integration into enterprise environments, enhancing data communication and printing workflow efficiency. It employs Zebra's XML-enabled printers and supports various barcode symbologies, including linear and 2D barcodes, facilitating versatile labeling solutions.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | Standard 8 MB DRAM, 4 MB Flash |
Custom Bundle | No |
MPN | 140-701-00000, LAN Network, Barcode |
Max. Resolution | 203 dpi |
Modified Item | No |
Supported Paper Size | Label Width: 5.63" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | 140XiIII Plus |
Connectivity | Serial RS-232, parallel, USB (varies by configuration), LAN (Ethernet) |
Features | Zebra Firmware |
Black Print Speed | 12in./Sec |
Product Line | Zebra Xi |
Printer Type | Industrial thermal transfer and direct thermal |
Print Method | Thermal transfer and direct thermal |
Print Resolution | 203 dpi (8 dots/mm), 300 dpi (12 dots/mm), 600 dpi (24 dots/mm) options |
Print Speed | Up to 14 inches per second (203 dpi), slower at higher resolutions |
Max Print Width | 4.09 inches (104 mm) |
Media Width | 1.00 to 4.65 inches (25.4 to 118 mm) |
Media Types | Continuous, die-cut, black mark, fanfold, notch media |
Media Roll Diameter | 8 inches (203 mm) maximum |
Ribbon | Maximum 3.2-inch (81.3 mm) O.D., 1-inch (25.4 mm) core, wax, wax/resin, and resin ribbons |
Dimensions | 12 in (W) x 17 in (D) x 14 in (H) approx. |
Weight | Approx. 40 lbs (18.1 kg) |
Operating Temperature | 40°F to 104°F (5°C to 40°C) |
Storage Temperature | -40°F to 140°F (-40°C to 60°C) |
Supported Barcodes | All major linear and 2D symbologies including Code 39, Code 128, UPC, PDF417, Data Matrix, QR Code |
Emulations | ZPL, ZPL II, EPL, XML-enabled printing |
Power Supply | Auto-ranging 90-264 VAC, 48-62 Hz |
Images
Key Advantages
The 140XiIII Plus offers exceptional print quality with its adjustable resolution options, catering to different application needs. Its robust construction ensures reliable operation in harsh industrial conditions, reducing downtime. The large media roll capacity minimizes the frequency of media changes, improving productivity. Network connectivity features support easy integration into existing infrastructure for centralized control. The printer's fast print speed contributes to efficient label production, crucial in high-demand environments. Additionally, compatibility with Zebra's advanced printing languages and barcode symbologies enhances versatility across various industries.
Limitations
The 140XiIII Plus, though highly capable, is relatively bulky and may require considerable space in smaller work areas. Initial setup and configuration can be complex, necessitating skilled personnel familiar with industrial printers and network settings. The printer's cost is higher compared to desktop alternatives, making it more suitable for businesses with substantial volume requirements. Replacement parts and maintenance might be less accessible for outdated models, potentially increasing operational costs. Some advanced features require additional firmware updates or accessory purchases. Furthermore, its age means it may lack some modern connectivity interfaces like USB 3.0 or wireless options included in newer devices.
FAQ
What print resolutions does the Zebra 140XiIII Plus support?
The printer supports 203, 300, and 600 dpi print resolutions, allowing for flexible label quality and detail.
Does the 140XiIII Plus have network connectivity options?
Yes, it includes LAN network connectivity for integration into enterprise printing environments.
What types of media are compatible with this printer?
It supports continuous, die-cut, black-marked, and fanfold media types up to 8 inches in outer diameter.
Is the Zebra 140XiIII Plus still in production?
No, the 140XiIII Plus is a discontinued model but remains in use in many industrial settings.
What are some typical applications for the 140XiIII Plus?
It is commonly used for printing high-quality barcode labels for manufacturing, shipping, and inventory management.
How durable is the 140XiIII Plus for industrial use?
It has a rugged design with a heavy-duty steel frame and die-cast components, making it very durable under harsh conditions.
Can the printer handle large print volumes?
Yes, its design supports high-volume printing with fast speeds and large media roll capacity.
