Zebra 140Xi4
Brand | Zebra 2014 |
Model | 140-801-00100, Network, LAN, Barcode, Ethernet |
Released Year | 2014 |
Type | Printers |
Series | Xi |
Status | Active |
Quick view
Overview
The Zebra 140Xi4 is an industrial-grade thermal barcode printer engineered for high-volume, high-quality label and tag printing. It features a robust 32-bit processor and a large memory capacity enabling fast, efficient printing and complex label formatting. Connectivity includes Ethernet and LAN network interfaces, facilitating integration into enterprise environments with ease. The printer supports various barcode symbologies and advanced printer languages compatible with most labeling systems. It uses thermal transfer and direct thermal printing technologies, ensuring long-lasting and durable label production. The model is designed for continuous, heavy-duty operation with a rugged metal frame and reliable mechanics suitable for manufacturing, logistics, and warehouse operations.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | 128 MB SDRAM, 64 MB Flash |
MPN | 140-801-00100, Network, LAN, Barcode, Ethernet |
Supported Paper Size | Maximum Label Width: 5.51" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | 140Xi4 |
Connectivity | 10/100 Ethernet, LAN, Serial, USB (optional) |
Features | Networkable, Cutter |
Black Print Speed | 14 in/Sec |
Product Line | Zebra Xi |
Print Method | Thermal transfer and direct thermal |
Print Width | Up to 4.09 inches (104 mm) |
Print Speed | Up to 14 inches per second |
Processor | 32-bit RISC processor |
Resolution | 203 dpi (8 dots per mm) standard, optional 300 dpi, 600 dpi |
Maximum Print Length | Up to 39 inches (991 mm) |
Media Types | Roll-fed, die-cut, continuous label, tag stock |
Barcode Symbologies | Code 39, Code 128, UPC, EAN, PDF417, DataMatrix, QR code, and others |
Operating Temperature | 40°F to 104°F (4.4°C to 40°C) |
Dimensions (WxHxD) | 11.5 x 11.7 x 19.5 inches (292 x 297 x 495 mm) |
Weight | Approx. 55 lbs (25 kg) |
Power Supply | AC 100-240V, 50-60 Hz |
User Interface | Multifunction LCD display |
Images
Key Advantages
The Zebra 140Xi4 offers exceptional print speed and precision suitable for high-demand industrial settings. Its rugged design ensures durability and operational longevity even in harsh environments. The integrated Ethernet and LAN capabilities provide seamless network connectivity, enhancing workflow efficiency. The printer supports a wide array of media types and sizes, offering versatility for various labeling requirements. Its advanced printer language compatibility simplifies integration with existing label design software and infrastructure. Additionally, the large memory and processing power enable complex label designs and rapid task handling, improving overall productivity.
Limitations
While robust, the 140Xi4's industrial design results in a heavier and larger form factor, which may limit placement flexibility in smaller office spaces. Initial setup and configuration can be complex for users unfamiliar with industrial printer networks. The cost of consumables such as ribbons and specialty labels can be higher compared to lower-end printers. Firmware updates and troubleshooting sometimes require technical expertise or professional support. The printer is optimized for heavy-duty use, which might be an over-specification for smaller-scale printing jobs. Its noise level during operation is relatively higher compared to desktop printers, which may be disruptive in quiet office environments.
FAQ
What printing technologies does the Zebra 140Xi4 support?
The Zebra 140Xi4 supports thermal transfer and direct thermal printing technologies.
Can the Zebra 140Xi4 connect to a network?
Yes, it includes Ethernet and LAN connectivity for network integration.
What types of labels can the 140Xi4 print?
It can print various label types including barcode labels, tags, and specialized media suited for industrial use.
Is the 140Xi4 suitable for high-volume printing?
Yes, it is designed for high-volume, continuous operation in industrial environments.
Does the printer support multiple barcode symbologies?
Yes, it supports a wide range of barcode symbologies and labeling languages.
What is the main frame material of the Zebra 140Xi4?
The printer features a rugged metal frame built for durability.
Is technical expertise required for setup?
While possible for experienced users, initial setup and network configuration may require technical knowledge or professional assistance.
