Zebra 140Xi4 image

Zebra 140Xi4

Quick information
Brand Zebra 2014
Model 140-801-00000
Released Year 2014
Type Printers
Series Xi4
Status Active
Quick view
Full specs Images

Overview

The Zebra 140Xi4 is an industrial-grade thermal transfer printer designed for high-volume printing applications. It features a durable metal frame that ensures stability and longevity in harsh manufacturing environments. The printer supports a wide range of label sizes and materials, making it versatile for various office electronics needs. Equipped with a fast 32-bit processor and high-resolution printhead options, it delivers crisp barcode and label printing at speeds up to 14 inches per second. Connectivity options include USB, serial, and Ethernet interfaces, facilitating easy integration into existing networks. The 140Xi4 supports multiple programming languages, including ZPL and EPL, enhancing compatibility with legacy systems.

Specifications

Output Type Black & White
Memory 64 MB SDRAM, 64 MB Flash
MPN 140-801-00000
Item Depth 20.4 in
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Item Height 15.5 in
Model 140Xi4
Connectivity USB 2.0, Serial, Parallel, Ethernet 10/100
Item Width 11.3 in
Product Line Zebra Xi4
Printer Type Industrial thermal transfer and direct thermal printer
Print Resolution 203 dpi (8 dots/mm), optional 300 dpi or 600 dpi
Print Width Up to 4.09 inches (104 mm)
Print Speed Up to 14 inches per second (355 mm/s)
Maximum Label Roll Diameter 8.0 inches (203 mm)
Processor 32-bit RISC with 266 MHz clock speed
Supported Languages ZPL, ZPL II, EPL, XML, ZebraBasic
Dimensions 10.4 x 16 x 14.6 inches (264 x 406 x 371 mm)
Weight 46 lbs (20.9 kg)
Operating Temperature 40°F to 104°F (5°C to 40°C)
Power Supply Input: 100-240 VAC, 50-60 Hz; Output: 24 VDC, 3.75A
Display Backlit LCD with keypad
Material Handling Label, tag, continuous, linerless media
Warranty Standard 1 year limited warranty

Key Advantages

The Zebra 140Xi4 offers exceptional durability with a rugged metal construction suitable for industrial use. It provides high-speed printing with precise label quality, boosting operational efficiency. The printer’s versatility supports a broad range of label sizes, materials, and types. Advanced connectivity options ensure seamless integration into diverse network environments. Its large memory and multiple programming language support enable flexible and efficient printing workflows. Additionally, the printer’s modular design allows for easy maintenance and upgrades.

Limitations

Despite its robust design, the 140Xi4 is relatively heavy and bulky, limiting portability. Initial investment and maintenance costs may be higher compared to smaller desktop printers. The printer requires trained personnel for optimal operation and troubleshooting. Some legacy connectivity interfaces may not support the latest network standards without adapters. Firmware updates might need manual intervention, as over-the-air updates are limited. Limited color printing options restrict usage primarily to monochrome thermal labels.

FAQ

The Zebra 140Xi4 uses thermal transfer printing technology, allowing it to produce durable and high-quality labels and barcodes.

The printer can achieve print speeds of up to 14 inches per second depending on the print resolution and label size.

It supports USB, serial, parallel, and Ethernet interfaces for versatile network integration.

Yes, it can accommodate label rolls up to 8.0 inches in diameter, supporting long print runs without frequent roll changes.

Yes, it supports Zebra’s ZPL and EPL programming languages for flexible label formatting and printing.

Regular cleaning of the printhead and platen rollers, along with firmware updates, helps maintain print quality and printer longevity.

No, the 140Xi4 is designed for monochrome thermal transfer printing and does not support color output.
