Zebra 110XiIII image

Zebra 110XiIII

Quick information
Brand Zebra 2007
Model R12-741-00000
Released Year 2007
Type Printers
Series Industrial
Status Discontinued
Quick view
Full specs Images

Overview

The Zebra 110XiIII is an industrial-grade thermal transfer printer designed for high-volume labeling applications. It supports a print resolution of up to 300 dpi for sharp barcode and text printing. The printer offers a robust metal frame for durability in demanding manufacturing environments. It is compatible with both direct thermal and thermal transfer printing methods, enabling versatile media usage. Connectivity options include parallel, serial, and USB interfaces ensuring flexible integration. Additionally, the printer supports a wide range of media widths up to 4.3 inches for extensive labeling capabilities.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 8 MB Flash, 16 MB SDRAM
MPN R12-741-00000
Supported Paper Size Up to 4 inches Wide
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Model 110XiIII
Connectivity Parallel, Serial (RS-232), USB
Features Networkable
Black Print Speed 10 IPS
Product Line Zebra Industrial
Print Method Thermal Transfer and Direct Thermal
Print Resolution 300 dpi (dots per inch)
Maximum Print Width 4.3 inches (109 mm)
Print Speed Up to 6 inches per second
Media Types Roll-fed, die-cut, continuous, black mark, fanfold, tag stock
Ribbon Types Wax, wax/resin, resin
Processor 32-bit RISC CPU
Dimensions (W x H x D) 250 mm x 262 mm x 447 mm
Weight 15.4 kg
Barcode Symbologies Code 39, Code 128, EAN-13, UPC, PDF417, QR Code, DataMatrix and others
Operating Temperature 5°C to 40°C (41°F to 104°F)
Power Supply 100-240 VAC, 50-60 Hz
Display LCD with button control panel
Fonts Multiple resident scalable fonts

Key Advantages

The Zebra 110XiIII is highly reliable for continuous, high-throughput printing tasks. Its durable construction provides excellent resistance to harsh industrial environments. With a maximum print speed of 6 inches per second, it delivers fast and efficient label production. The printer supports an extensive variety of barcode symbologies and fonts for versatile applications. Its user-friendly interface simplifies operation and maintenance. Moreover, the 110XiIII's expandable options allow tailoring the device for specific industrial needs.

Limitations

Despite its strengths, the Zebra 110XiIII has a relatively high power consumption compared to newer models. Its physical size and weight can be cumbersome for limited workspace environments. The printer's interface lacks some modern connectivity options like Ethernet or wireless support. Firmware upgrades and software support may be limited due to its age. It also requires specialized ribbons and media which may not be readily available everywhere. Lastly, the user interface does not provide advanced touchscreen controls, which can limit ease-of-use.

FAQ

The printer supports both thermal transfer and direct thermal printing technologies.

The maximum print resolution is 300 dots per inch (dpi).

Yes, it supports media widths up to 4.3 inches, suitable for various label sizes.

The 110XiIII is discontinued, so support and parts availability may be limited and need to be sourced through third parties.

The printer includes parallel, serial, and USB interfaces for connectivity.

No, the 110XiIII does not support wireless connectivity out of the box.

It is commonly used in manufacturing, warehousing, and logistics for durable barcode and label printing.
