Zebra 110Xi4 image

Zebra 110Xi4

Quick information
Brand Zebra 2009
Model 113-801-00000, 300Dpi, Ethernet Network, Parallel, Serial, Barcode, Transfer
Released Year 2009
Type Printers
Series Xi
Status Discontinued
Quick view
Full specs Images

Overview

The Zebra 110Xi4 is an industrial thermal transfer printer engineered for high-volume barcode label printing. Featuring a robust print mechanism, it supports a resolution of 300 dots per inch, delivering crisp, high-quality prints. Connectivity options include Ethernet, parallel, and serial interfaces, providing flexible integration in various enterprise environments. The printer is designed to handle multiple barcode symbologies and supports a broad range of transfer and direct thermal media types. Its modular design allows expansion and customization to suit specific industrial label printing requirements. Advanced firmware ensures efficient print job management and compatibility with leading barcode standards.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 32 MB SDRAM, 8 MB Flash
Custom Bundle No
MPN 113-801-00000, 300Dpi, Ethernet Network, Parallel, Serial, Barcode, Transfer
Supported Paper Size Max. Width: 4.5"
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Technology Thermal
Maximum Resolution 300 x 300 DPI
Model 110Xi4
Connectivity Ethernet, Parallel, Serial
Features Networkable, RFID Ready
Black Print Speed 14 ips
Product Line Zebra Xi
UPC 807027540683
Print Technology Thermal Transfer and Direct Thermal
Print Resolution 300 dpi (dots per inch)
Print Width 4.09 inches (104 mm)
Print Speed Up to 14 inches per second (356 mm/s)
Media Types Supported Labels, tags, receipt paper
Barcode Symbologies Supports Code 39, Code 128, UPC, EAN, and more
Dimensions 14.5 x 15.5 x 20 inches
Weight Approximately 38 lbs (17.2 kg)
Power 100-240V AC, 50-60Hz
Operating Temperature 40°F to 104°F (5°C to 40°C)

Key Advantages

The Zebra 110Xi4 offers exceptional print clarity at 300 dpi, ideal for detailed barcode labels. Its multiple interface options (Ethernet, parallel, serial) facilitate versatile connectivity in complex office networks. The robust build ensures reliable performance in demanding industrial environments. Support for numerous barcode formats and media types increases operational flexibility. Firmware upgrades and modular components enable easy maintenance and future-proofing. Additionally, it supports precise registration for label and tag printing, enhancing print accuracy.

Limitations

The 110Xi4's industrial size and weight make it less portable compared to desktop printers. Initial setup and configuration can be complex for non-technical users due to extensive configuration options. Its power consumption is higher than that of basic office printers. The cost of consumables and replacement parts can be significant for small operations. Firmware updates require technical knowledge to avoid misconfigurations. While versatile, the printer may overperform for low-volume or occasional printing tasks, making it less economical in such cases.

FAQ

The printer supports a wide range of thermal transfer and direct thermal media including labels, tags, and receipts suitable for industrial applications.

It offers Ethernet, parallel, and serial communication interfaces, allowing flexible integration into various network setups.

The 110Xi4 model has been discontinued, and official support may be limited. However, Zebra offers support for similar models in the Xi series.

The 110Xi4 supports 300 dots per inch (dpi) resolution, which provides high-quality printing for detailed barcodes and graphics.

Yes, it is designed for barcode printing and supports numerous barcode symbologies required in industrial and logistics operations.

This printer is built with a rugged frame and industrial components designed to withstand harsh manufacturing and warehouse environments.

Yes, it includes Ethernet connectivity allowing it to be used as a network printer within office or industrial LAN setups.
