Zebra 105SL
Brand | Zebra 1999 |
Model | 10500-2001-3000 |
Released Year | 1999 |
Type | Printers |
Printing Technology | Thermal transfer |
Status | Discontinued |
Quick view
Overview
The Zebra 105SL is an industrial-grade thermal transfer printer designed primarily for high-volume label printing. It supports resolutions of 203 dpi, delivering clear and durable barcode labels suitable for industrial environments. This printer utilizes a robust metal frame and is equipped with a fast processor to ensure efficient printing speeds. Connectivity options include parallel and serial interfaces, facilitating integration with various host systems. It supports a wide range of media types and widths, accommodating different labeling needs. The device firmware supports Zebra's ZPL programming language, enabling customized label design and advanced printer control.
Specifications
MPN | 10500-2001-3000 |
Model | 105SL |
Technology | Thermal |
Connectivity | Parallel, Serial RS-232 |
Output Type | Black & White |
Type | Label Printer |
Weight | Approximately 40 lbs (18.1 kg) |
Depth | 20in |
Height | 16in |
Width | 11in |
Extend Printer Technology | Direct Thermal / Thermal Transfer |
Installed RAM | 6MB |
Data Link Protocol | IEEE 802.11b, Ethernet |
Form Factor | Desktop, Stationary |
Networking Type | 10baset/2, Print Server (Optional) |
Media Type | Roll-fed labels and tags |
Printers Special Features | Autocutter, Remote Management |
Panel | Monochrome LCD |
Max Resolution (Bw) | 203DPI |
Max Media Size | Roll (11.4cm) |
Black Print Speed | 8in/Sec |
Media Capacity | 1 Roll(s) |
Release Date | May, 2001 |
Printing Technology | Thermal transfer |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 4.1 inches (104 mm) |
Print Speed | Up to 5 inches per second |
Memory | 2 MB DRAM, 1 MB Flash |
Dimensions (WxDxH) | 12.5 x 17.5 x 13 inches |
Media Width | 0.79 inches to 4.5 inches |
Firmware | Zebra Programming Language (ZPL) |
Power | 100-240V AC, 50/60 Hz |
Operating Temperature | 40°F to 104°F (5°C to 40°C) |
Images
Key Advantages
The Zebra 105SL offers industrial durability with a rugged metal frame built to withstand harsh production environments. It delivers reliable and high-quality printing with a 203 dpi resolution suited for complex barcode and label printing. The printer supports multiple interface options, making it adaptable to existing network configurations. High-speed printing capabilities improve operational efficiency in busy production lines. Its wide media compatibility ensures flexibility across various labeling applications. Additionally, the inclusion of the Zebra Programming Language (ZPL) allows for extensive customization and control.
Limitations
Despite its strengths, the Zebra 105SL's connectivity options might be considered outdated compared to modern networked printers as it lacks built-in Ethernet or wireless capabilities. Its maximum print speed is relatively moderate compared to newer models. The printer supports only 203 dpi resolution; higher resolutions available on other models could be better for fine-detail printing. Replacement parts and consumables may be harder to source due to the device's age. It has a relatively large physical footprint, requiring significant space in the work area. Its user interface is limited, lacking modern touchscreen controls present in newer printers.
FAQ
What type of printing technology does the Zebra 105SL use?
The Zebra 105SL uses thermal transfer printing technology for producing durable barcode labels.
What is the maximum print resolution of the Zebra 105SL?
The printer supports a maximum print resolution of 203 dots per inch (dpi).
Does the Zebra 105SL support network connectivity?
The Zebra 105SL primarily supports serial and parallel interfaces; it does not have built-in Ethernet or wireless connectivity.
Is the Zebra 105SL still in production?
No, the Zebra 105SL has been discontinued and is no longer manufactured.
Which programming language is compatible with the Zebra 105SL?
The printer uses Zebra Programming Language (ZPL), allowing custom label design and print control.
What types of media can the Zebra 105SL handle?
It supports a variety of media types, including rolls of paper and synthetic labels of different widths and thicknesses.
Where can replacement parts for the Zebra 105SL be found?
Replacement parts may be sourced through Zebra's authorized service centers or specialized third-party suppliers for legacy equipment.
