SATO CG408DT-LAN
| Brand | SATO 2018 |
| Model | 4x6 Inch, Network, Commercial, WWCG08041 |
| Released Year | 2018 |
| Type | Printers |
| Series | Cg |
| Status | Active |
Quick view
Overview
The SATO CG408DT-LAN is a high-performance commercial label printer designed for continuous operation in office and industrial environments. It supports 4x6 inch label printing at a resolution of 203 dpi, utilizing direct thermal and thermal transfer printing technologies. Featuring an Ethernet LAN interface, it provides reliable network connectivity for easy integration into enterprise systems. The printer's compact design allows for efficient space utilization while maintaining ruggedness for durability in demanding conditions. It supports various print media including continuous, die-cut, and black mark labels, expanding its versatility. The CG408DT-LAN has an intuitive LCD display and supports multiple programming languages for compatibility with existing workflows.
Note that the printer is part of the CG series, emphasizing commercial-grade performance and flexibility.
Specifications
| Input Type | Monochrome |
| Output Type | Black & White |
| Memory | 16 MB SDRAM, 8 MB Flash |
| MPN | 4x6 Inch, Network, Commercial, WWCG08041 |
| Supported Paper Size | Max. Label Width: 4.21" |
| California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
| Type | Label Printer |
| Technology | Thermal |
| Maximum Resolution | 203 x 203 DPI |
| Model | CG408DT-LAN |
| Connectivity | Ethernet (RJ-45), USB 2.0 |
| Features | Portable |
| Black Print Speed | 4 ips |
| Product Line | SATO CG |
| Print Method | Direct Thermal / Thermal Transfer |
| Resolution | 203 dpi (8 dots/mm) |
| Maximum Print Width | 4.1 inches (104 mm) |
| Maximum Print Length | 39 inches (991 mm) |
| Print Speed | Up to 6 inches per second (152 mm/s) |
| Media Type | Die-cut, continuous, black mark labels |
| Media Width | 1.18 to 4.65 inches (30 to 118 mm) |
| Media Thickness | 0.0024 to 0.0095 inches (0.06 to 0.24 mm) |
| Interface | Ethernet (10/100 Mbps) |
| Display | LCD with 8 buttons |
| Dimensions (W x D x H) | 202 x 265 x 172 mm |
| Weight | Approximately 3.8 kg |
| Power Supply | 100-240 VAC, 50/60 Hz |
| Operating Environment | 5 to 40°C, 10 to 85% non-condensing humidity |
| Compatible Ribbons | Wax, wax/resin, resin ribbons |
Images
Key Advantages
The CG408DT-LAN offers robust network capabilities through its LAN interface enabling seamless connection in business environments.
Its compact yet durable design ensures longevity and efficient use of space in busy office setups.
The dual printing methods (direct thermal and thermal transfer) provide flexibility for various labeling needs.
Supports a wide range of label types including die-cut, continuous, and black mark for versatile applications.
High print quality at 203 dpi ensures clear and precise label output suitable for commercial standards.
User-friendly interface and compatibility with multiple printer languages facilitate easy integration and operation.
Limitations
The print speed, while efficient, may be slower compared to newer high-speed industrial printers in the market.
The 203 dpi resolution, although standard, may not satisfy requirements for very high-detail barcode or graphics printing.
The device may lack wireless connectivity options like Wi-Fi or Bluetooth, limiting flexible installation.
Limited color printing capabilities constrain usage to mono or single-color labels only.
Relatively higher power consumption compared to some modern energy-efficient models.
The user interface might be less intuitive for novice users compared to newer touchscreen models.
FAQ
What printing technologies does the SATO CG408DT-LAN support?
The CG408DT-LAN supports both direct thermal and thermal transfer printing technologies, enabling versatile label printing options.
Does the CG408DT-LAN support network connectivity?
Yes, it features an Ethernet LAN interface for reliable network connectivity and integration into enterprise systems.
What label sizes are supported by this printer?
The printer is designed for 4x6 inch labels primarily, supporting various label types including die-cut, continuous, and black mark labels.
Can the CG408DT-LAN print in color?
No, this model supports monochrome printing only, usually black on white labels.
Is the printer still in production?
As of current information, the CG408DT-LAN is not discontinued and is available for purchase.
What programming languages or command sets does the printer support?
The printer supports multiple printer command languages including SATO's native SBPL for compatibility with various software systems.
What maintenance is required for the CG408DT-LAN?
Routine maintenance includes cleaning the printhead and platen roller, replacing consumables like ribbons and labels, and occasional firmware updates.
