Monarch Specialties 9416XL image

Monarch Specialties 9416XL

Quick information
Brand Monarch Specialties 1990
Model 9416XL
Released Year 1990
Type Printers
Series Avery Dennison Monarch
Printing Technology Direct Thermal
Status Discontinued
Quick view
Full specs Images FAQ

Overview

The Avery Dennison Monarch 9416XL is a thermal label printer widely used in office and industrial environments. It features direct thermal printing technology, which eliminates the need for ink or toner cartridges. The device supports a print resolution of 203 dpi, providing clear and legible labels. The 9416XL model offers a printing speed of up to 2 inches per second, suitable for moderate volume labeling tasks. Connectivity options include parallel and serial ports, allowing integration with various office systems. The printer supports multiple label widths up to 2.3 inches and has adjustable labeling mechanisms for different media types.

Specifications

Device Type Thermal Label Printer
Printing Technology Direct Thermal
Print Resolution 203 dpi
Print Speed 2 inches per second
Max Label Width 2.3 inches (58 mm)
Connectivity Serial (RS-232), Parallel (IEEE 1284), USB 2.0
Media Type Thermal labels
Power Supply AC powered
Dimensions (WxDxH) Approx. 8.5 x 7.5 x 6 inches
Weight Approx. 4.5 kg
Operating Temperature 5°C to 40°C
Warranty Varies by seller, typically 1 year
Output Type Black & White
MPN 9416XL
Avery Dennison Monarch 9416XL Direct Thermal
Supported Paper Size Max Label Width: 4.4"
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Model 9416XL
Features Shipping Labels
Black Print Speed 4 ips
Product Line Avery Dennison Monarch

Key Advantages

The Monarch 9416XL boasts user-friendly operation with simple loading of label rolls. Its thermal printing technology ensures low maintenance and operating cost by eliminating ink and toner. The compact design fits well in office settings without occupying excessive desk space. High print quality with 203 dpi resolution meets common labeling standards. It supports multiple connectivity options for versatile integration. Durable construction ensures long-term reliability in office and light industrial use.

Limitations

The printer is limited to black-and-white thermal printing, unsuitable for color labeling needs. Print speed of 2 ips may be slower compared to modern high-speed label printers. It lacks advanced connectivity such as USB or network interfaces common in newer models. The maximum label width is limited to 2.3 inches, restricting some applications. Being an older model, driver support for current operating systems may be limited. The absence of a touch screen interface means reliance on manual settings and host device control.
