Intermec PM4i
Brand | Intermec 2007 |
Model | PM4D010000000020, Network LAN, Barcode |
Released Year | 2007 |
Type | Printers |
Series | Easycoder |
Status | Discontinued |
Quick view
Overview
The Intermec EasyCoder PM4i is a high-performance industrial barcode printer designed for heavy-duty labeling applications. It supports multiple connectivity options including Network LAN, ensuring seamless integration within enterprise environments. The printer features a robust print mechanism capable of printing high-resolution labels at fast speeds, suitable for both barcode and text printing. Its construction includes a durable metal frame optimized for industrial usage and longevity. The printer supports a variety of media types and widths, providing versatile label printing capabilities. Additionally, the integrated control panel facilitates easy configuration and operation.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | 8 MB Flash, 16 MB RAM |
Custom Bundle | No |
MPN | PM4D010000000020, Network LAN, Barcode |
Supported Paper Size | Max. Width: 4.50" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | PM4i |
Connectivity | USB type-B, Serial (RS-232 DB9), Ethernet (RJ-45), USB 2.0 |
Features | Networkable |
Black Print Speed | 7.6 ips |
Country/Region of Manufacture | Malaysia |
Product Line | Intermec EasyCoder |
UPC | Does not apply |
Release Year | 2007 |
Printer Type | Industrial Barcode Printer |
Print Technology | Thermal Transfer / Direct Thermal |
Print Resolution | 203 dpi |
Print Speed | Up to 6 inches per second |
Max Print Width | 4.1 inches (104 mm) |
Media Types | Labels, Tags, Continuous Media |
Media Width | 0.75 to 4.65 inches (19 to 118 mm) |
Interface | Network LAN, USB, Serial, Parallel |
Control Panel | LCD Display with 4 buttons |
Supported Barcodes | Code 39, Code 128, UPC/EAN, Interleaved 2 of 5, PDF417, QR Code, and others |
Dimensions (W x H x D) | 410 x 308 x 326 mm |
Weight | Approx. 14.5 kg |
Operating Temperature | 0°C to 40°C |
Power Supply | 100–240 VAC, 50/60 Hz |
Programming Languages | IPL, ZSim (ZPL emulation), DPL |
Images
Key Advantages
The PM4i stands out with its exceptional print speed, enhancing productivity in demanding environments. Its LAN connectivity allows for convenient integration and centralized management within network infrastructures. The printer is compatible with a wide range of labeling materials, accommodating diverse industrial needs. The rugged metal chassis increases durability and reliability in harsh conditions. User-friendly interface and programming languages support custom label creation and printer control. Furthermore, the device supports advanced barcode symbologies, enhancing its utility across different industries.
Limitations
Despite its robust features, the PM4i may have a relatively higher initial investment compared to entry-level printers. Its size and weight can limit portability, making it less suitable for mobile applications. The complexity of configuration may require trained personnel for setup and maintenance. Limited support for color printing confines usage primarily to monochrome labels. Some users may find the printer software and drivers require updates for newer operating systems. Additionally, the device's consumables and parts might be costlier compared to consumer-grade printers.
FAQ
What is the maximum print resolution of the Intermec PM4i?
The Intermec PM4i supports a maximum print resolution of 203 dpi (dots per inch).
Does the PM4i support network connectivity?
Yes, the PM4i includes Network LAN connectivity for easy integration into enterprise networks.
What type of labels can be printed with the PM4i?
It supports a wide range of label types including barcode labels, text labels, and tags of varying widths.
Is the Intermec PM4i still in production?
No, the PM4i has been discontinued but remains supported with spare parts and accessories.
What are the dimensions and weight of the PM4i printer?
The PM4i measures approximately 410 mm (W) x 308 mm (H) x 326 mm (D) and weighs around 14.5 kg.
What interfaces does the PM4i support besides LAN?
Besides LAN, the PM4i supports serial, USB, and parallel connections.
Does the printer support color printing?
No, the PM4i is a monochrome printer primarily designed for black-and-white label printing.
