Intermec 3400
Brand | Intermec 2004 |
Model | 3400 |
Released Year | 2004 |
Type | Printers |
Series | Easycoder |
Printing Technology | Thermal Transfer / Direct Thermal |
Status | Discontinued |
Quick view
Overview
The Intermec EasyCoder 3400 is a thermal transfer desktop printer designed primarily for label and barcode printing applications. Utilizing direct thermal and thermal transfer technologies, it ensures high-quality, durable prints suitable for various industrial environments. This printer supports a print width of up to 4 inches (104 mm) and a resolution of 203 dpi, delivering sharp and precise outputs. Connectivity options include serial and parallel interfaces, enabling integration with a wide range of host systems. Its compact architecture is engineered for efficient performance and ease of use, including an intuitive control panel and straightforward media loading mechanism. The printer accommodates media rolls with a maximum diameter of 5 inches, making it suitable for medium-duty printing tasks in office and industrial settings.
Specifications
Supported Scanning Sizes | -- |
Input Type | Monochrome |
Grayscale Depth | -- |
Color Depth | -- |
Output Type | Black & White |
Memory | 2 MB RAM, 2 MB Flash memory |
Custom Bundle | No |
Supported Paper Size | Max Width: 4,5" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Printer Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Manufacturer Warranty | -- |
Image Sensor | -- |
Model | 3400 |
Connectivity | Serial RS-232, Parallel IEEE 1284 |
Features | Industrial |
Scanning Resolution | -- |
Black Print Speed | 5 ips |
Product Line | Intermec EasyCoder |
UPC | Does not apply |
Printing Technology | Thermal Transfer / Direct Thermal |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 4 inches (104 mm) |
Maximum Print Length | Up to 39 inches (991 mm) |
Print Speed | Up to 4 inches per second |
Media Types Supported | Labels, tags, continuous media |
Media Roll Diameter | Maximum 5 inches (127 mm) |
Media Core Diameter | 1 inch (25.4 mm) standard |
Processor | 32-bit RISC processor |
Dimensions | 9.4 in (W) x 8.5 in (D) x 6.0 in (H) |
Weight | Approx. 6.8 lbs (3.1 kg) |
Power Supply | External power adapter, 100-240 VAC |
Operating Systems Compatibility | Windows 95/98/NT/2000 (limited support) |
Fonts and Graphics | Supports scalable fonts, barcode symbologies including Code 39, Code 128, UPC, EAN, Interleaved 2 of 5 |
Accessories | Optional peel and present module, cutter |
Durability | Plastic housing with metal chassis for moderate industrial use |
Images
Key Advantages
The EasyCoder 3400's compact design provides excellent space savings for office environments. It offers reliable and consistent print quality through stable thermal transfer technology. Its user-friendly interface reduces the learning curve and improves operational efficiency. The device supports a variety of label media, enhancing its versatility across different applications. Low maintenance requirements and robust build quality contribute to minimal downtime. Additionally, it provides flexible connectivity with both serial and parallel ports, increasing compatibility with legacy systems.
Limitations
The printer operates at a resolution of 203 dpi which may be insufficient for applications requiring ultra-fine or high-resolution printing. It lacks modern connectivity options such as USB or network interfaces, which limits integration capabilities in contemporary IT infrastructures. Media capacity is relatively modest with a 5-inch core max roll diameter, potentially requiring frequent media replacement during large print runs. The print speed is moderate compared to newer models, potentially limiting productivity in high-volume environments. Firmware and software support for the EasyCoder 3400 have been discontinued, affecting compatibility with current operating systems. Moreover, it does not support color printing, restricting it to monochrome label outputs.
FAQ
What types of media can the Intermec EasyCoder 3400 print on?
The EasyCoder 3400 supports thermal transfer and direct thermal media, including labels, tags, and continuous media designed for barcode and labeling applications.
What is the maximum print resolution of the EasyCoder 3400?
The printer offers a maximum print resolution of 203 dots per inch (dpi), suitable for standard barcode and label printing.
Does the EasyCoder 3400 support modern connectivity options like USB or Ethernet?
No, the EasyCoder 3400 includes serial and parallel ports but does not support USB or Ethernet connectivity, limiting its integration options with current systems.
Can this printer handle high-volume printing tasks?
While reliable, the EasyCoder 3400 is better suited for medium-duty printing due to its moderate media capacity and print speed.
Is the Intermec EasyCoder 3400 still supported by the manufacturer?
No, the EasyCoder 3400 has been discontinued and no longer receives firmware updates or technical support from Intermec.
What is the maximum media roll size supported by the EasyCoder 3400?
It supports media rolls with a maximum diameter of 5 inches (127 mm), which covers most standard desktop label supplies.
Does the EasyCoder 3400 print in color?
No, this model is a monochrome printer and does not support color printing.
