GoDEX G500
| Brand | GoDEX 2019 |
| Model | G500 |
| Released Year | 2019 |
| Type | Printers |
| Series | G500 |
| Item Weight | 8.18 pounds |
| Product Dimensions | 11.2 x 6.8 x 8.9 inches |
| Status | Discontinued |
Quick view
Overview
The GoDEX G500 is a robust thermal transfer and direct thermal label printer designed for medium-volume office and industrial printing needs. It features a high-resolution 203 dpi printhead capable of delivering clear, sharp labels and tags. The device supports a print width up to 104 mm and print speed up to 5 inches per second, balancing quality and speed effectively. Connectivity includes USB and serial ports, enabling versatile interfacing with various operating systems and software environments. The printer is equipped with an easy-to-use LCD interface for intuitive configuration and status monitoring. Its durable construction ensures reliability in demanding label printing applications.
Specifications
| Included Components | Labels, Label Stand |
| Print media | Labels |
| Max Input Sheet Capacity | 15000 |
| Sheet Size | 4 inches |
| Maximum Black and White Print Resolution | 203 dpi |
| Warranty Type | limited warranty |
| Dual-sided printing | No |
| Maximum copies per run | 1000 |
| Max copy resolution black-white | 203 dpi |
| Duplex | Simplex |
| Hardware Interface | USB |
| Ink Color | Black, Cyan, Magenta, Yellow |
| Additional Printer functions | Print Only |
| Control Method | Remote |
| Processor Count | 1 |
| Series Number | 500 |
| Total Ethernet Ports | 1 |
| Number of USB 2 Ports | 1 |
| Total USB Ports | 1 |
| Memory Storage Capacity | 64 MB |
| Product Dimensions | 11.2 x 6.8 x 8.9 inches |
| Item Weight | 8.18 pounds |
| Item model number | G500 |
| Is Discontinued By Manufacturer | No |
| Date First Available | January 3, 2019 |
| Manufacturer | GODEX |
| Printer Type | Thermal Transfer / Direct Thermal |
| Print Resolution | 203 dpi |
| Print Speed | Up to 5 inches per second |
| Print Width | Maximum 104 mm |
| Connectivity | USB 2.0, Serial (RS-232) |
| Memory | 2 MB Flash, 8 MB SDRAM |
| Display | Backlit LCD panel |
| Media Type | Continuous, die-cut, black mark, fan-fold labels |
| Ribbon Type | Wax, Wax/Resin, Resin |
| Media Width | 20 mm to 110 mm |
| Media Roll Diameter | Up to 127 mm |
| Dimensions | 260 mm x 195 mm x 170 mm |
| Weight | 3.5 kg |
| Operating Systems Supported | Windows XP, Vista, 7, 8, 10 |
| Power Supply | External 24V DC power adapter |
Images
Key Advantages
The GoDEX G500 offers flexible media handling with support for both thermal transfer and direct thermal printing. Its compact design saves workspace while maintaining high print performance. User-friendly software drivers and emulation support enable smooth integration into existing workflows. The printer’s affordable price point provides excellent value for small to medium businesses. Efficient ribbon-saving capability reduces operating costs over prolonged use. Moreover, it offers consistent print quality suitable for barcode labeling, shipping, and product identification.
Limitations
The GoDEX G500's maximum resolution of 203 dpi might not meet needs for ultra-high-definition printing. It lacks wireless connectivity options, limiting mobility in some setups. The print speed, while adequate, may be slower compared to contemporary industrial printers for very high volume demands. Limited internal memory restricts complex label formats or large font storage. It does not support advanced networking features like Ethernet or Wi-Fi out of the box. Additionally, replacement of printheads and maintenance might require professional service in some cases.
FAQ
What types of labels can the GoDEX G500 print?
The GoDEX G500 supports both thermal transfer and direct thermal labels, making it suitable for various label materials including paper and synthetic labels.
What is the maximum print resolution of the GoDEX G500?
The printer offers a maximum print resolution of 203 dpi, providing clear and legible text and barcodes.
Does the GoDEX G500 support USB connectivity?
Yes, the printer includes USB and serial port interfaces for easy connection to computers and peripherals.
Is the GoDEX G500 still available for purchase?
No, the GoDEX G500 model has been discontinued and is no longer in production.
What print speed can be expected from the GoDEX G500?
The printer can achieve speeds up to 5 inches per second, suitable for medium volume labeling tasks.
Does the GoDEX G500 support wireless printing?
No, this model does not have built-in wireless connectivity options such as Wi-Fi or Bluetooth.
What operating systems are compatible with the GoDEX G500?
It supports popular operating systems including various versions of Windows through dedicated drivers.
