OM SYSTEM PEN E-P1
| Brand | OM SYSTEM 2009 |
| Model | Silver w/ 17mm Lens |
| Released Year | 2009 |
| Type | Point & Shoot Digital Cameras |
| Series | PEN |
| Color | Silver |
| Compatible Mountings | Micro Four Thirds |
| Autofocus | Yes |
| Photo Sensor Resolution | 12 MP |
| Video Resolution | 720p |
| Optical Zoom | 3 |
| File Format | JPEG |
| Status | Discontinued |
Quick view
Overview
The OM SYSTEM PEN E-P1 Silver w/ 17mm Lens is a Micro Four Thirds mirrorless digital camera introduced in 2009. It features a 12.3-megapixel Live MOS sensor designed for superior image quality and low noise performance. The camera incorporates the Four Thirds system mount, allowing access to a wide range of interchangeable lenses. It supports RAW image capture and includes in-camera Art Filters for creative shooting options. The 2.7-inch LCD screen facilitates image composition and playback, although it lacks a built-in viewfinder. Powered by a lithium-ion battery, the E-P1 enables wireless image transfer through optional accessories. Its compact, retro-styled magnesium alloy body measures approximately 121.5 x 71.8 x 38.4 mm, making it highly portable for everyday photography.
The camera employs a contrast-detection autofocus system with multiple AF points to ensure precise focusing. ISO sensitivity ranges from 100 to 3200, providing flexibility in various lighting conditions. It supports shutter speeds from 60 seconds to 1/4000 second for versatile exposure control. The E-P1 also offers multiple shooting modes including aperture priority, shutter priority, and manual exposure. Video recording is limited and not a primary feature of this model.
Specifications
| Built-In Media | Olympus E-P1 Pen Digital Camera Body - M.ZUIKO |
| Are Batteries Included | No |
| Remote Included | No |
| Series Number | 2 |
| Global Trade Identification Number | 00050332169821 |
| UPC | 050332169821 |
| Item Height | 2.76 inches |
| Manufacturer | Olympus |
| Metering Methods | Multi, Center-weighted, Spot |
| Exposure Control | Multiple |
| White Balance Settings | Auto |
| Crop Mode | 16:9 |
| Screen Size | 3 Inches |
| Display Type | LCD |
| Display Fixture Type | Fixed |
| Display Resolution Maximum | 230,000 |
| Has Color Screen | Yes |
| Flash Memory Type | SD/SDHC card |
| Write Speed | 3 fps or higher |
| Compatible Mountings | Micro Four Thirds |
| Sensor Type | CMOS |
| Image stabilization | Sensor-shift |
| Maximum Aperture | 2.8 f |
| Expanded ISO Minimum | 100 |
| Photo Sensor Resolution | 12 MP |
| Photo Sensor Size | Four Thirds (17.3 x 13 mm) |
| Maximum Shutter Speed | 1/4000 Seconds |
| Minimum Shutter Speed | 60 seconds |
| Form Factor | Mirrorless |
| Special Feature | In-Camera Art Filters, Multiple Exposures, Multi-Aspect Shooting, Stereo Audio, Retro-Chic Design |
| Color | Silver |
| Item Weight | 0.78 Pounds |
| Video Resolution | 720p |
| Viewfinder | None (external optional accessory available) |
| Flash Modes | Slow Sync |
| Camera Flash | no flash |
| Skill Level | Professional |
| Compatible Devices | [INFERRED] Devices with USB 2.0, HDMI, and SD/SDHC card support |
| Continuous Shooting | 3 |
| Aperture modes | F2.8 |
| Audio Input | Built-in Microphone |
| Flash Sync Speed | 1/180_sec |
| Video Capture Format | MJPEG |
| Expanded ISO Maximum | 6400 |
| Delay between shots | 0.33 seconds |
| Audio Output Type | Internal |
| Battery Cell Type | Lithium Ion |
| Battery Average Life | 300 Photos |
| Battery Type | Lithium-Ion BLS-1 rechargeable battery & charger |
| Aspect Ratio | 16:9 |
| File Format | JPEG |
| Effective Still Resolution | 12.3 MP |
| JPEG Quality Level | Fine |
| Maximum Image Size | 12.3 MP |
| Bit Depth | 24 Bit |
| Total Still Resolution | 12.3 MP |
| Maximum Focal Length | 84 Millimeters |
| Optical Zoom | 3 |
| Lens Type | fixed |
| Zoom | Optical |
| Camera Lens | The camera comes with a wide-angle 17mm lens with an f/2.8 aperture, suggesting good low light performance. |
| Minimum Focal Length | 17 Millimeters |
| Real Angle Of View | 65.2 Degrees |
| Number of Diaphragm Blades | 7 |
| Connectivity Technology | HDMI, USB |
| Wireless Technology | Yes |
| Video Output | HDMI |
| Total USB 2.0 Ports | 1 |
| Total Video Out Ports | 2 |
| Shooting Modes | Automatic, Landscape, Portrait, Scene |
| Digital-Still | Yes |
| Movie Mode | Yes |
| Image Capture Type | Stills & Video |
| Night vision | No |
| Auto Focus Technology | Continuous, Contrast Detection, Face Detection, Live View, Multi-area, Selective single-point, Single |
| Focus Features | Contrast Detection |
| Autofocus Points | 11 |
| Focus Type | automatic with manual |
| Focus Mode | Continuous-Servo AF (AF-C) |
| Autofocus | Yes |
| Camera type | Mirrorless Digital Camera |
| Sensor | 12.3 Megapixel Live MOS Sensor |
| Sensor size | 17.3 x 13.0 mm (Four Thirds system) |
| Image processor | TruePic III |
| Lens mount | Four Thirds mount |
| Included lens | 17mm f/2.8 Pancake Lens |
| ISO sensitivity | ISO 100 - 3200 |
| Autofocus system | Contrast-detection AF with multiple AF points |
| Shutter speed range | 60 sec to 1/4000 sec |
| Continuous shooting speed | Approx. 3 fps |
| Display | 2.7-inch LCD, approx. 230,000 dots |
| Video recording | Limited to none |
| Exposure modes | Program, Aperture Priority, Shutter Priority, Manual |
| White balance | Auto, Preset, Custom |
| Image formats | JPEG, RAW (ORF) |
| Storage media | SD / SDHC cards |
| Connectivity | USB 2.0, HDMI output via adapter, optional wireless adapter |
| Battery type | Rechargeable Li-ion battery (BLS-1) |
| Dimensions | 121.5 x 71.8 x 38.4 mm |
| Weight | Approx. 334 grams (body only) |
| Body material | Magnesium alloy and metal top plate |
Images
Key Advantages
The OM SYSTEM PEN E-P1 delivers excellent image quality with its 12.3MP Live MOS sensor tailored for Micro Four Thirds standards. Its compact and lightweight body with magnesium alloy construction provides durability and portability. The camera offers flexible lens compatibility via the Four Thirds lens mount system. Inclusion of in-camera creative Art Filters enhances photographic expression without post-processing. Its silent contrast-detection autofocus is ideal for street and candid photography. Additionally, its manual controls enable experienced photographers to fine-tune exposure settings easily.
Limitations
The E-P1 does not include a built-in viewfinder, which may challenge framing in bright outdoor conditions. Autofocus speed is slower compared to contemporary phase-detection systems. Continuous shooting speed is limited to approximately 3 frames per second, restricting action photography. Video capabilities are minimal or absent, signaling its focus on still photography. LCD screen resolution and size are modest compared to newer models. Battery life is moderate, requiring spare batteries for extended shooting sessions.
FAQ
What type of sensor does the OM SYSTEM PEN E-P1 have?
The PEN E-P1 features a 12.3-megapixel Live MOS sensor for high-quality image capture.
Does the PEN E-P1 have a built-in viewfinder?
No, the PEN E-P1 does not have a built-in viewfinder and relies on its LCD screen for image composition.
Can the PEN E-P1 record video?
Video recording is very limited or not available on the PEN E-P1; it is primarily a still photography camera.
What lens mount does the PEN E-P1 use?
It uses the Four Thirds system lens mount, compatible with a variety of lenses designed for this format.
What is the ISO range of the OM SYSTEM PEN E-P1?
The ISO range spans from 100 to 3200, allowing flexibility in diverse lighting conditions.
Is the PEN E-P1 still supported or discontinued?
The PEN E-P1 was discontinued; production ceased several years ago.
What type of autofocus system is used in the PEN E-P1?
It employs a contrast-detection autofocus system with multiple focusing points.
