Samsung QB75R
Brand | Samsung 2018 |
Model | QB75R |
Released Year | 2018 |
Type | TV |
Screen Size | 75 in |
Resolution | 3840 x 2160 (4K UHD) |
Refresh Rate | 120 Hz |
Display Technology | LED |
Status | Active |
Quick view
Overview
The Samsung QB75R is a 75-inch UHD commercial display designed primarily for professional and business environments. It features a 4K (3840 x 2160) resolution panel utilizing VA technology which provides high contrast ratios and wide viewing angles ideal for signage applications. The display operates with a brightness of approximately 500 nits ensuring visibility even in well-lit environments. It supports HDR content and includes Tizen OS for smart functionality and easy content management. Connectivity options include HDMI, DisplayPort, USB ports, and RJ45 for network integration. The display supports Daisy Chain setup for extended video walls and features integrated cooling systems tailored for prolonged usage.
The panel's 120Hz refresh rate enhances motion handling for dynamic content, while the Anti-Glare coating reduces reflections. The device is engineered to operate 16/7 hours per day making it suitable for retail, transportation, and hospitality sectors. Samsung integrates MagicInfo content management software support allowing remote control and scheduling capabilities.
Specifications
Display Technology | LED |
Screen Size | 75 in |
Maximum Resolution | 2160p (4K) |
Refresh Rate | 120 Hz |
Color | Black |
Model | QB75R |
Features | Wall Mountable, Glossy Screen, Wi-Fi / Bluetooth, Pivot Adjustment, Built-In Speakers |
MPN | LH75QBREBGCXZA |
Country/Region of Manufacture | Vietnam |
Audio/Video Inputs | Audio-In Jack (3.5mm), HDMI, USB 2.0, DisplayPort 1.2 |
UPC | does not apply |
Display Size | 75 inches |
Resolution | 3840 x 2160 (4K UHD) |
Panel Technology | VA (Vertical Alignment) |
Brightness | 500 nits |
Aspect Ratio | 16:9 |
Operating System | Samsung Tizen OS |
HDR Support | HDR10 (basic HDR support) |
Connectivity | HDMI 3 ports, DisplayPort 1.2, USB 2.0 x2, USB 3.0 x1, RJ45 Ethernet, RS232C |
Speaker Output | 10W x 2 |
Daisy Chain Support | Yes |
Usage Rating | 16/7 hours per day |
Dimensions (WxHxD) | Approx. 1672.1 x 963.7 x 59.9 mm (without stand) |
Weight | Approx. 38.5 kg |
Anti-Glare | Yes |
Cooling System | Integrated fan cooling |
Color Gamut | 72% NTSC |
Viewing Angle | 178° (H) / 178° (V) |
Power Consumption | Approximately 210W |
Images
Key Advantages
The QB75R excels with its 4K UHD resolution delivering stunning image clarity and detail for commercial purposes. Its VA panel technology ensures excellent color reproduction and contrast important for advertising content. High brightness level of 500 nits helps maintain visibility in brightly lit areas without compromising image quality. The built-in Tizen OS platform provides seamless smart features and easy management of multimedia content. Wide connectivity options including multiple HDMI ports and USB allow for versatile multimedia integration. The display’s durability and design support long operational hours, optimizing it for continuous professional use.
Limitations
While powerful for its intended use, the QB75R does not have built-in speakers loud enough for large venues, necessitating external audio systems. The 75-inch size might be impractical for smaller spaces or limited mounting options. Its Tizen-based smart functionality, though convenient, limits the available apps compared to general consumer smart TVs. The device lacks HDR10+ support, only supporting basic HDR content formats. Compared to newer models, the refresh rate at 120Hz might be less effective for ultra-fast motion video applications. Finally, external control requires familiarity with MagicInfo software, possibly limiting use for non-technical users.
FAQ
What is the panel type used in the Samsung QB75R?
The Samsung QB75R uses a VA (Vertical Alignment) panel, which provides deep blacks and wide viewing angles suitable for commercial displays.
Does the QB75R support HDR content?
Yes, the QB75R supports basic HDR content enhancing dynamic range and color depth but does not support advanced HDR10+ formats.
What connectivity options are available on the QB75R?
Connectivity includes multiple HDMI ports, DisplayPort, USB 2.0/3.0 ports, RJ45 Ethernet port, and RS232C for external control.
Is the Samsung QB75R suitable for continuous commercial usage?
Yes, it is rated for 16/7 usage making it ideal for most commercial applications such as retail signage and information displays.
Does the QB75R have built-in speakers?
Yes, it has built-in speakers, but these are generally insufficient for large public spaces, so external speakers may be necessary.
What operating system does the QB75R use?
The display runs on Samsung's Tizen OS, providing smart functionality and content management features.
Can multiple QB75R units be connected for video walls?
Yes, the QB75R supports Daisy Chain configuration allowing multiple displays to be connected and operated as a video wall.
