ZebraNet TLP2824
Brand | ZebraNet 2018 |
Model | TLP2824 |
Released Year | 2018 |
Type | Printers |
Series | TLP |
Printing Technology | Direct Thermal |
Item Weight | 5 pounds |
Status | Discontinued |
Quick view
Overview
The ZebraNet TLP2824 is a compact thermal label printer designed primarily for office or small business use. It utilizes direct thermal printing technology, enabling high-quality printouts without the need for ink or toner cartridges. The printer supports print widths of up to 2.2 inches (56mm) with a resolution of 203 dpi, which ensures clear and precise barcode and text printing. Its serial and parallel port connectivity options allow integration with various legacy systems. The TLP2824 is known for its straightforward media loading design, facilitating easy replacement of label rolls. Equipped with an internal power supply, the printer offers a consistent and reliable printing experience suitable for moderate volume office tasks.
Specifications
Printing Technology | Direct Thermal |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 2.2 inches (56 mm) |
Print Speed | Up to 4 inches per second (102 mm/s) |
Connectivity | Serial (RS-232), Parallel (IEEE 1284) |
Media Types | Continuous, Die-cut labels, Black mark labels |
Media Width | 0.5 inch - 2.28 inches (12.7 mm - 58 mm) |
Media Roll Diameter | Up to 5 inches (127 mm) |
Memory | Standard built-in with no expansion |
Power Supply | Internal |
Dimensions (WxDxH) | 8.25 x 6.5 x 6.5 inches (210 x 165 x 165 mm) |
Weight | Approx. 3.5 lbs (1.6 kg) |
Operating Systems Supported | Windows, DOS, and some Linux with drivers |
Discontinued | Yes |
Print media | Labels |
Max Input Sheet Capacity | 500 |
Compatible Devices | PC |
Maximum Black and White Print Resolution | 203 dpi |
Dual-sided printing | No |
Max copy resolution black-white | 203 dpi |
Duplex | Simplex |
Hardware Interface | USB |
Additional Printer functions | Print Only |
Total USB Ports | 1 |
UPC | 732387105633 |
Package Dimensions | 11.5 x 9.25 x 9 inches |
Item Weight | 5 pounds |
Item model number | TLP2824 |
Is Discontinued By Manufacturer | No |
Date First Available | November 20, 2018 |
Manufacturer | ZebraNet |
Images
Key Advantages
The ZebraNet TLP2824 boasts a compact design, making it ideal for tight office spaces. It offers direct thermal printing, which reduces consumable costs by eliminating the need for ink ribbons. The printer supports a variety of label types including continuous, die-cut, and black mark media. Its user-friendly interface and easy media loading mechanism reduce downtime and improve operational efficiency. The device’s multiple connectivity options enhance compatibility with existing office hardware. Additionally, the reliable printing mechanism ensures consistent output for barcode and label applications.
Limitations
One limitation of the TLP2824 is its relatively low print resolution of 203 dpi, which may not meet requirements for extremely detailed graphics or very small barcodes. It only supports direct thermal printing, lacking thermal transfer capabilities for longer-lasting labels. The maximum print width is limited to 2.2 inches, restricting its use for wider labels. The connectivity ports are legacy serial and parallel interfaces without modern USB or network options, which may pose integration challenges. It does not have built-in memory or advanced features found in newer models, limiting customization. Additionally, since this model is discontinued, obtaining spare parts and accessories can be difficult.
FAQ
What type of printing technology does the ZebraNet TLP2824 use?
The ZebraNet TLP2824 uses direct thermal printing technology, which involves heating thermal-sensitive paper to produce images without ink or toner.
What is the maximum print width of the TLP2824 printer?
The maximum print width supported by the TLP2824 is 2.2 inches (56 mm).
Does the TLP2824 printer support thermal transfer printing?
No, the TLP2824 only supports direct thermal printing and does not have thermal transfer capabilities.
What connectivity options are available with the ZebraNet TLP2824?
The printer offers serial and parallel port connectivity, which are considered legacy interfaces.
Is the ZebraNet TLP2824 still in production?
No, the ZebraNet TLP2824 has been discontinued and is no longer in production.
Can the TLP2824 handle a variety of label types?
Yes, it supports multiple types of media including continuous, die-cut, and black mark labels.
What is the print resolution of the TLP2824?
The ZebraNet TLP2824 has a print resolution of 203 dots per inch (dpi).
