ZEBRA - MOBILE QLn320
Brand | ZEBRA - MOBILE 2018 |
Model | QLn320 |
Released Year | 2018 |
Type | Printers |
Series | QLn |
Item Weight | 1.6 pounds |
Maximum Color Print Resolution | 203 x 203 DPI |
Status | Active |
Quick view
Overview
The Zebra QLn320 is a compact and rugged mobile printer engineered for efficient on-the-go label and receipt printing. Featuring a 3-inch (72 mm) print width and direct thermal printing technology, it delivers high-quality monochrome output without requiring ink or toner. The printer supports resolutions of 203 dpi, ensuring clear barcode and text printing suitable for diverse industrial applications. Connectivity options include Bluetooth, 802.11a/b/g/n WLAN, and USB 2.0, enabling seamless integration with handheld devices and mobile computing solutions. It is powered by a rechargeable, all-in-one battery that supports continuous printing in challenging environments. The device also boasts a fast print speed of up to 4 inches per second combined with an intuitive user interface for ease of use in dynamic workspaces.
Specifications
Included Components | QLn320 Mobile Printer, Battery |
Print media | Labels |
Scanner Type | Portable |
Max Input Sheet Capacity | 50 |
Compatible Devices | PC, Smartphones |
Maximum Color Print Resolution | 203 x 203 DPI |
Sheet Size | 4 inches |
Maximum Black and White Print Resolution | 203 dpi |
Warranty Type | 90 days limited warranty |
Dual-sided printing | No |
Max copy resolution black-white | 203 dpi |
Duplex | Simplex |
Hardware Interface | Ethernet, USB |
Ink Color | Black |
Resolution | 203 x 203 DPI |
Additional Printer functions | Print Only |
Control Method | App |
Series Number | 320 |
Total Ethernet Ports | 1 |
Total USB Ports | 1 |
UPC | 748926420013 |
Printer Ink Type | No Ink |
Memory Storage Capacity | 128 MB |
Package Dimensions | 12.44 x 10.55 x 5.87 inches |
Item Weight | 1.6 pounds |
Item model number | QLn320 |
Is Discontinued By Manufacturer | No |
Date First Available | September 7, 2018 |
Manufacturer | ZEBRA - MOBILE |
Printer Type | Mobile Thermal Printer |
Print Method | Direct Thermal |
Max Print Width | 3 inches (72 mm) |
Print Resolution | 203 dpi (8 dots/mm) |
Print Speed | Up to 4 inches per second |
Connectivity | Bluetooth 3.0, 802.11a/b/g/n WLAN, USB 2.0 |
Memory | 128 MB Flash, 64 MB SDRAM |
Battery | Rechargeable Li-Ion 3250 mAh (7.2V), field-replaceable |
Dimensions | 4.75 in (L) x 3.9 in (W) x 7.1 in (H) |
Weight | 1.4 lbs (0.64 kg) with battery |
Durability | MIL-STD 810G drop specification, IP54 rated for dust and water resistance |
Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
Label Roll Capacity | Up to 2.25 inches (57 mm) diameter |
Software Compatibility | Supports Zebra Link-OS, Print DNA, and multiple software SDKs |
Images
Key Advantages
The Zebra QLn320 offers excellent portability with its lightweight and ergonomic design, making it ideal for field or retail environments. It provides robust wireless connectivity options, including Wi-Fi and Bluetooth, ensuring versatile pairing across various devices. The printer’s rugged construction meets MIL-STD 810G standards, making it resistant to drops, dust, and moisture for reliable operation in demanding conditions. Its direct thermal printing technology eliminates the need for ink cartridges, reducing maintenance and operating costs. The device features quick battery swapping capability for minimal downtime during extended printing tasks. High-resolution printing combined with fast throughput allows for efficient label and receipt generation, improving operational productivity.
Limitations
The Zebra QLn320's reliance on direct thermal paper means labels are susceptible to fading with prolonged exposure to heat or light, limiting archival longevity. Its monochrome printing capability restricts applications requiring color-coded labels or graphics. Although equipped with wireless features, initial connectivity setup may require some technical expertise for seamless integration. The printer’s print width of 3 inches may not accommodate larger label formats necessary in some specialized uses. Battery life, while sufficient for most tasks, may require frequent recharging in very high-volume printing scenarios. Additionally, its firmware updates depend on compatibility with supporting software, which could pose limitations if outdated.
FAQ
What printing technology does the Zebra QLn320 use?
The Zebra QLn320 uses direct thermal printing technology, which prints by selectively heating thermal paper, eliminating the need for ink or toner.
What are the connectivity options available on the QLn320?
The QLn320 supports multiple connectivity options including Bluetooth, Wi-Fi (802.11a/b/g/n), and USB 2.0 for versatile device integration.
What is the maximum print resolution and width of the QLn320?
It offers a print resolution of 203 dpi with a maximum print width of 3 inches (72 millimeters).
Is the QLn320 suitable for harsh environments?
Yes, the QLn320 is designed with a rugged build and meets MIL-STD 810G standards, making it resistant to drops, dust, and moisture.
How long does the battery last during printing operations?
Battery life varies depending on usage, but the rechargeable battery is designed to support a typical work shift with quick swap capabilities to minimize downtime.
Can the QLn320 print color labels?
No, the QLn320 only supports monochrome printing as it utilizes direct thermal printing technology.
Is the Zebra QLn320 still in production?
No, the Zebra QLn320 is not discontinued and continues to be supported and used in various industries.
