TSC TTP-245 Plus

Quick information
Brand TSC 2015
Model AC Adapter, Ethernet
Released Year 2015
Type Printers
Series Ttp
Status Discontinued
Quick view
Full specs Images FAQ

Overview

The TSC TTP-245 Plus is a thermal transfer desktop label printer designed for medium duty use in office and industrial environments. The device supports direct thermal and thermal transfer printing methods, utilizing a compact design suitable for desktop placement. It features a 203 dpi print resolution with a print speed of up to 6 inches per second, ensuring quality and efficiency. Connectivity options include USB and parallel interfaces; Ethernet connectivity may require additional adapters or accessories. The printer supports a wide range of label materials and sizes, enabling diverse label printing applications. Its firmware is compatible with common printer languages, facilitating integration with various systems.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 8 MB SDRAM, 4 MB Flash
MPN AC Adapter, Ethernet
Supported Paper Size Max Label Width: 4.4"
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Model TTP-245 Plus
Connectivity Ethernet (RJ-45), Parallel (IEEE 1284), Serial (RS-232), USB 2.0
Features Networkable, Portable
Black Print Speed 5 ips
Product Line TSC TTP
Printer Type Thermal Transfer / Direct Thermal
Print Resolution 203 dpi (8 dots/mm)
Print Speed Up to 6 inches per second (152 mm/sec)
Max Print Width 4.25 inches (108 mm)
Media Type Roll or fan-fold labels, tags, continuous paper
Interface USB 2.0, Parallel; Optional Ethernet adapter
Power Supply External AC Adapter
Dimensions 250 mm x 196 mm x 180 mm
Weight 2.5 kg (5.5 lbs)
Operating Temperature 5 to 40°C (41 to 104°F)
Supported Barcode Symbologies Code 39, Code 128, EAN-13, UPC-A, Interleaved 2 of 5, QR Code, PDF417
Compatibility Windows drivers, common printer languages

Key Advantages

The TTP-245 Plus provides high-quality 203 dpi print resolution for clear label output. Its compact and robust design fits well in office environments. The printer boasts fast printing speeds that enhance productivity for batch label printing. Supported direct thermal and thermal transfer printing modes increase versatility for different labeling requirements. Easy-to-use interface and compatibility with multiple barcode types improve operational efficiency. Availability of AC adapters and Ethernet modules allows flexibility in power and connectivity configurations.

Limitations

The TTP-245 Plus does not include built-in Ethernet connectivity by default; networking requires additional modules. Its printing speed may be slower compared to high-end industrial models for very large volume needs. The device primarily supports standard label sizes, limiting custom large format printing. Firmware updates for newer features or protocols are limited due to the device's age. It uses thermal transfer ribbons that may require frequent replacement in heavy-duty printing scenarios. Compatibility with modern software platforms may require driver updates or middleware integration.
