Star Micronics Tsp143iiiu
| Brand | Star Micronics 2017 |
| Model | TSP143IIIU |
| Released Year | 2017 |
| Type | Printers |
| Series | Tsp |
| Item Weight | 4.09 pounds |
| Product Dimensions | 5.59 x 8.03 x 5.2 inches |
| Status | Active |
Quick view
Overview
The Star Micronics TSP143IIIU is a high-speed thermal receipt printer designed for efficient point-of-sale environments. It features a USB 2.0 interface that ensures fast and reliable data transfer. The printer supports a print speed of up to 250mm per second, enhancing transaction efficiency. Equipped with a 203 dpi resolution thermal print head, the TSP143IIIU delivers sharp and clear receipts. It accommodates paper widths of 80mm, making it compatible with standard POS receipt rolls. The device supports multiple command sets including StarPRNT and ESC/POS, facilitating wide compatibility with existing POS software systems.
Specifications
| Print Method | Direct Thermal |
| Print Resolution | 203 dpi |
| Print Speed | Up to 250 mm/sec |
| Interface | USB 2.0 |
| Paper Width | 80 mm |
| Paper Thickness | 53 to 85 microns |
| Cutter | Full or Partial Guillotine Cutter |
| Command System | StarPRNT, ESC/POS Compatible |
| Power Supply | External Power Supply Included |
| Dimensions | 142 mm (W) x 204 mm (D) x 132 mm (H) |
| Weight | 1.5 kg |
| Operating Temperature | 5°C to 45°C |
| Humidity | 10% to 90% non-condensing |
| Reliability | MCBF 60 million lines |
| Warranty | 1 Year Limited Warranty |
| MPN | TSP143IIIU |
| UPC | 766234133562 |
| Model | Star Micronics TSP143IIIU |
| Output Type | Black & White |
| Technology | Thermal |
| Input Type | Monochrome |
| Type | Point of Sale Printer |
| Maximum Resolution | 203 x 203 DPI |
| Connectivity | USB 2.0 |
| Scanning Resolution | 200x200 DPI |
| Product Line | Star Micronics TSP |
| Compatible Devices | PC |
| Sheet Size | 80 millimeters |
| Maximum Black and White Print Resolution | 203 dpi |
| Warranty Type | 90 days limited warranty |
| Color Depth | 1 bpp |
| Dual-sided printing | No |
| Max copy resolution black-white | 300 dpi |
| Duplex | Simplex |
| Hardware Interface | USB |
| Ink Color | Black |
| Additional Printer functions | Print Only |
| Control Method | Remote |
| Processor Count | 1 |
| Series Number | 143 |
| Number of USB 2 Ports | 1 |
| Total USB Ports | 1 |
| Printer Ink Type | No Ink |
| Product Dimensions | 5.59 x 8.03 x 5.2 inches |
| Item Weight | 4.09 pounds |
| Item model number | TSP143IIIU |
| Is Discontinued By Manufacturer | No |
| Date First Available | July 25, 2019 |
| Manufacturer | Star Micronics |
Images
Key Advantages
The TSP143IIIU offers rapid printing speeds facilitating quick customer checkout processes. Its plug-and-play USB connectivity simplifies installation and setup. Compact and sleek design fits well in limited counter spaces. Energy Star compliant, it is designed to be energy efficient conserving power without sacrificing performance. The printer integrates a guillotine cutter, enhancing convenience and reducing paper jams. Built with durable materials, it ensures consistent performance in high-volume retail environments.
Limitations
The TSP143IIIU is limited to USB connectivity, lacking Ethernet or wireless options which restricts deployment flexibility. It only supports thermal paper and does not support ink ribbon printing, limiting media options. The device is primarily focused on receipt printing and lacks multifunction features such as scanning or copying. No SD card or similar onboard memory is provided for standalone operation. Its compatibility is mainly with Star Micronics and ESC/POS command protocols, possibly requiring adapters for other systems. The peripheral lacks a display or interactive touchscreen, limiting direct user interaction.
FAQ
What interface does the TSP143IIIU support?
The TSP143IIIU supports USB 2.0 interface for high-speed data transfer.
What is the maximum print speed of the TSP143IIIU?
It can print receipts at speeds up to 250mm per second.
What paper sizes are compatible with the TSP143IIIU?
The printer uses 80mm width thermal paper rolls.
Does the TSP143IIIU support wireless connectivity?
No, it only supports USB connectivity; wireless options are not available.
Is the TSP143IIIU energy efficient?
Yes, it is Energy Star compliant ensuring lower power consumption.
Does the printer include a paper cutter?
Yes, it comes with an automatic guillotine cutter for ease of use.
Is the TSP143IIIU compatible with all POS software?
It supports StarPRNT and ESC/POS command protocols, ensuring compatibility with many popular POS software, but some systems may require additional configuration.
