PARTS ZD220
| Brand | PARTS 2023 |
| Model | ZD220 |
| Released Year | 2023 |
| Type | Printers |
| Series | ZD220, ZD230 |
| Printing Technology | Direct Thermal |
| Item Weight | 3.52 ounces |
| Status | Active |
Quick view
Overview
The PARTS ZD220 is a compact desktop label printer designed for office and light industrial use, offering reliable thermal printing technology for barcode labels and shipping tags.
This printer employs direct thermal printing, eliminating the need for ink or toner, which reduces maintenance requirements and operational costs.
With a maximum print resolution of 203 dpi, it delivers clear and precise barcode and text printing suitable for inventory and retail applications.
The device supports a print speed of up to 6 inches per second, ensuring quick label production to boost workplace efficiency.
Connectivity options include USB and optional Ethernet or Bluetooth interfaces, providing flexible integration with various systems.
The ZD220 series is part of the ZD220 and ZD230 lineup, known for their user-friendly design, smart media handling, and compatibility with existing printer setups.
Specifications
| Maximum Black and White Print Resolution | 203 dpi |
| Warranty Type | Limited |
| Dual-sided printing | No |
| Max copy resolution color | 203 x 203 DPI |
| Max copy resolution black-white | 203 dpi |
| Duplex | Simplex |
| Hardware Interface | USB |
| Ink Color | Black |
| Additional Printer functions | Print Only |
| Control Method | Touch |
| Total USB Ports | 1 |
| Printer Ink Type | No Ink |
| Item Weight | 3.52 ounces |
| Item model number | ZD220 |
| Date First Available | July 20, 2023 |
| Manufacturer | PARTS |
| Printing Technology | Direct Thermal |
| Print Resolution | 203 dpi (8 dots/mm) |
| Maximum Print Speed | 6 inches per second (152 mm/s) |
| Maximum Print Width | 4.09 inches (104 mm) |
| Media Types | Roll-fed labels, die-cut labels, tag stock, receipt paper |
| Media Width | 0.75 inches to 4.25 inches (19 mm to 108 mm) |
| Connectivity | USB 2.0 standard; optional Ethernet 10/100 Mbps; optional Bluetooth 4.0 |
| Memory | 512 MB Flash; 256 MB SDRAM |
| Display | Monochrome LCD |
| Dimensions (W x D x H) | 7.3 in x 6.6 in x 7.7 in (185 mm x 168 mm x 195 mm) |
| Weight | 3.6 lbs (1.6 kg) |
| Power Supply | AC Adapter, 100-240V, 50-60 Hz |
| Operating Systems Supported | Windows, Mac OS, Linux |
| Fonts | Standard fonts including CPCL, ZPL, EPL emulations |
| Environmental Operating Range | 40°F to 105°F (5°C to 40°C) humidity 10-90% non-condensing |
Images
Key Advantages
The compact size allows easy placement in limited office spaces without sacrificing performance.
Direct thermal printing technology reduces running costs by eliminating ink consumption.
Fast print speed enhances productivity in busy labeling environments.
Multiple connectivity choices offer seamless integration with computers and networks.
Simple media loading and intuitive operation minimize setup time and user errors.
The compatibility within the ZD220 and ZD230 series ensures smooth migration and scalability for growing business needs.
Limitations
Print resolution is limited to 203 dpi, which may not be adequate for highly detailed or color-intensive labels.
Direct thermal printing is susceptible to fading over time, making it unsuitable for long-term label durability.
The device primarily supports smaller label rolls, restricting applications requiring wide format printing.
Lack of built-in wireless connectivity in base models may require additional accessories for full mobility.
Some users might find the monochrome display less informative compared to advanced touchscreen interfaces.
Firmware updates and advanced customization options are somewhat limited compared to higher-end models.
FAQ
What types of labels can the ZD220 printer print?
The ZD220 supports direct thermal labels such as barcode labels, shipping labels, and inventory tags.
Does the ZD220 require ink or toner?
No, the ZD220 uses direct thermal printing technology, which does not require ink or toner.
What connectivity options are available for the ZD220?
Standard connectivity is USB, with optional Ethernet and Bluetooth modules available for expanded networking options.
Can the ZD220 handle large label rolls?
No, it is designed for smaller label rolls and is not compatible with wide format or large roll sizes.
Is the ZD220 suitable for outdoor label printing?
Due to direct thermal printing, labels may fade outdoors; therefore, it is better suited for indoor applications.
Is the ZD220 still supported by PARTS?
Yes, as of now, it has not been discontinued and continues to receive support.
Are there accessories available for the ZD220 printer?
Yes, accessories such as label rolls, ribbons (if compatible), Ethernet and Bluetooth adapters are available.
