OKI 320 TURBO image

OKI 320 TURBO

Quick information
Brand OKI 1998
Model 91907101
Released Year 1998
Type Printers
Series Microline
Printing Technology 9-pin impact dot matrix
Status Discontinued
Quick view

Overview

The OKI Microline 320 Turbo is a robust 9-pin impact dot matrix printer designed primarily for office environments requiring reliable continuous-form printing. It delivers a high-speed printing performance with speeds up to 435 characters per second, optimized for business printing needs. Engineered with a serial interface alongside parallel and USB connectivity options, it ensures versatile compatibility with legacy and modern systems. The printer supports multiple form types including single-sheet and multi-part carbon copies, offering adaptability in various document handling scenarios. Featuring a rugged construction with a durable print head, the 320 Turbo is tailored for continuous and heavy-duty applications. Additionally, it incorporates emulation modes such as Epson ESC/P, enhancing its interoperability in mixed-device settings.

This model’s print mechanism harnesses wire impact printing technology, enabling clear, sharp outputs on various media types. Its tractor feed design supports wide paper widths and different thicknesses, crucial for forms and invoices. The device’s control panel and software driver suite facilitate straightforward operation and configuration, enabling efficient print job management in office workflows.

Specifications

Grayscale Depth 8 Bit
Maximum Resolution 240 x 216 DPI
Scanning Resolution 200x200 DPI
Country/Region of Manufacture Thailand
California Prop 65 Warning Yes
Supported Paper Size A4 (210 x 297 mm), A5 (148 x 210 mm)
UPC 0051851440538
Input Type Monochrome
Output Type Black & White
MPN 91907101
Item Length 15.7in.
Type Dot Matrix
Technology Dot Matrix
Item Height 5.8in.
Model 320 TURBO
Connectivity Cable, Parallel (IEEE 1284), USB 1.0/1.1
Features Copier
Black Print Speed 435 CPS
Item Width 13.6in.
Product Line OKI Microline
GTIN 0051851440538
Printing Technology 9-pin impact dot matrix
Print Speed Up to 435 characters per second (cps)
Print Resolution 240 x 144 dpi (approximate impact quality)
Interfaces Serial (RS-232), Parallel (IEEE1284), USB
Paper Handling Continuous tractor-fed paper, multi-part forms up to 5 copies
Emulation Epson ESC/P compatible
Operating Voltage AC 100-120V or AC 220-240V (depends on region)
Dimensions (WxDxH) Approx. 12.6 x 6.2 x 4.7 inches (320 x 158 x 120 mm)
Weight Approx. 4.5 kg
Noise Level Approx. 58 dB(A)
Memory Approx. 128 KB buffer
Duty Cycle High - designed for continuous heavy use
Driver Support Windows (legacy), DOS, and limited UNIX support

Key Advantages

The OKI Microline 320 Turbo offers exceptional printing speeds for a 9-pin dot matrix printer, significantly reducing document processing times. Its compatibility with multiple legacy and modern interfaces enhances integration flexibility within diverse IT infrastructures. The ability to print multi-part forms up to 5 copies is instrumental for businesses requiring multiple document copies simultaneously. The printer's sturdy build quality ensures long operational life under continuous, heavy usage conditions. The support for Epson ESC/P emulation broadens the range of software compatibility without requiring reconfiguration. Lastly, the low operational noise level for an impact printer improves office environment comfort during extended use.

Limitations

Being an impact dot matrix printer, the OKI Microline 320 Turbo produces lower print resolution compared to modern laser and inkjet printers, limiting its suitability for high-quality graphics. The printing color capability is restricted to monochrome output, which is less ideal for color-dependent documents. Its reliance on continuous feed paper and tractor feeding mechanisms may not be convenient for standard cut-sheet office paper usage. The printer design and technology are somewhat outdated, potentially complicating driver support with newer operating systems. Limited onboard memory restricts the size and complexity of print jobs it can process efficiently. Lastly, the printer's physical size and weight reduce portability, making it better suited as a fixed workstation device.
