Intermec PM43
| Brand | Intermec 2015 |
| Model | PM43A0100000020, Ethernet, Barcode |
| Released Year | 2015 |
| Type | Printers |
| Series | Pm |
| Status | Active |
Quick view
Overview
The Intermec PM43 is an advanced industrial barcode printer designed primarily for high-volume label printing applications. It features an embedded Ethernet interface for seamless network connectivity, facilitating integration into complex office electronics ecosystems. The printer supports a print resolution of 203 dpi, suitable for sharp barcode and label printing. It incorporates a 32-bit RISC processor to accelerate data processing and printing speed, reaching up to 14 ips. The device is equipped with a user-friendly color touchscreen display for intuitive control and configuration. Compatible with a broad range of media types and widths, the PM43 offers versatility in printing different label formats and sizes.
Specifications
| Printer Type | Industrial barcode label printer |
| Print Technology | Thermal transfer and direct thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 14 inches per second (356 mm/s) |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB |
| Connectivity | Serial (RS-232 DB9), Ethernet (RJ-45), USB 2.0 |
| User Interface | 4.3-inch color touchscreen display |
| Media Handling | Roll-fed labels, die-cut labels, continuous media, tags |
| Max Media Width | 4.65 inches (118 mm) |
| Max Print Width | 4.1 inches (104 mm) |
| Max Media Roll Diameter | 8 inches (203 mm) |
| Sensors | Reflective, transmissive, head-open |
| Supported Barcodes | 1D and 2D symbologies including Code 39, Code 128, QR, Data Matrix, PDF417 |
| Operating Temperature | Operating: 5°C to 40°C; Storage: -40°C to 60°C |
| Power Supply | Internal universal power supply (100-240 VAC) |
| Dimensions (WxDxH) | 263 mm x 432 mm x 245 mm |
| Weight | Approximately 8.6 kg |
| Optional Features | RFID encoding, cutter, peel-and-present module |
| Compliance | ENERGY STAR qualified, RoHS compliant |
| Input Type | Monochrome |
| Output Type | Black & White |
| MPN | PM43A0100000020, Ethernet, Barcode |
| Supported Paper Size | Maximum Label Width: 4.50" |
| California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
| Type | Label Printer |
| Technology | Thermal |
| Maximum Resolution | 203 x 203 DPI |
| Model | PM43 |
| Features | Networkable |
| Black Print Speed | 12 ips |
| Product Line | Intermec PM |
| UPC | 885080578348 |
Images
Key Advantages
The PM43 excels in high-speed printing reliability and quality output, making it ideal for demanding office environments. Its Ethernet connectivity ensures fast and stable data transfer for efficient workflow. The modular design permits easy maintenance and upgrades, reducing operational downtime. It supports various barcode symbologies and RFID encoding options, enhancing functionality. The touchscreen interface simplifies user interaction and printer management. Additionally, the device offers robust construction to endure harsh industrial office conditions.
Limitations
While the PM43 provides 203 dpi resolution, it may not satisfy requirements for ultra-high resolution label printing. The device’s physical size and weight can be cumbersome for small office spaces. Firmware updates require careful management to prevent compatibility issues. Its initial cost is higher compared to entry-level printers, potentially limiting accessibility for small businesses. Some users report a learning curve in configuring advanced settings via the touchscreen interface. Replacement parts and accessories may have limited availability outside major distribution channels.
FAQ
What type of connectivity does the PM43 support?
The Intermec PM43 supports Ethernet connectivity as a standard interface, allowing integration into networked office environments.
What is the maximum print speed of the PM43 printer?
The PM43 can print at speeds up to 14 inches per second, facilitating high-volume label production.
Is the PM43 suitable for printing RFID labels?
Yes, certain configurations of the PM43 support RFID encoding options to print and program RFID labels.
What is the print resolution of the PM43 printer?
The PM43 features a print resolution of 203 dots per inch (dpi), adequate for standard barcode label printing.
Does the PM43 have a user interface for configuration?
Yes, the PM43 includes a color touchscreen display that enables easy access to settings and printer status.
Can the media width be adjusted on the PM43?
Yes, the PM43 supports a range of media widths and types to accommodate various label sizes and formats.
Is the Intermec PM43 still supported or discontinued?
As of now, the PM43 is not discontinued and continues to receive support and updates from the manufacturer.
