Honeywell PC300T/ PC42E-T

Quick information
Brand Honeywell 2011
Model PC300T/ PC42E-T
Released Year 2011
Type Printers
Status Active
Quick view
Full specs Images

Overview

The Honeywell PC300T and PC42E-T are industrial label printers designed for high-performance office and manufacturing environments. They support thermal transfer printing technology, enabling durable and high-quality label production. With print speeds up to 4 inches per second and resolutions of 203 dpi, they balance efficiency and clarity. The printers feature a compact design for space-saving installation while offering robust durability in various conditions. Connectivity options include USB and serial interfaces, facilitating integration with existing systems. The devices support multiple label formats and barcode symbologies, making them versatile for inventory management and shipping applications.

Specifications

Connectivity USB, Serial (RS-232)
Default Print Speed 100 mm/s (4.0 ips)
Display 1 Feed Button, 1 ECO Button and LED
Input 90~264V voltage
Maximum Media Diameter 5.0 in (127 mm)
Maximum Print Length 190 in (4826 mm) for 203dpi
Maximum Print Speed 203 dpi: 6ips
Maximum Print Width 104 mm (4.1 inches)
Maximum Resolution 203 dpi
Maximum Ribbon Diameter 2.7 in (68 mm)
Media Core Sizes 1 in (25.4 mm); 1.5 in (38.1 mm)
Media Width 1 in to 4.5 in (25.4 mm to 114 mm)
Memory Standard 8 MB SDRAM, 4 MB Flash
Minimum Label Length 0.37 in (9.6 mm)
Model PC300T/ PC42E-T
MPN PC300T/ PC42E-T
Native Graphic Formats 1-bit BMP, GIF, PCX, PNG
Operating Temperature 5°C to 40°C (41°F to 104°F)
Output 24V DC, 2.5 A
Print Resolution 203 dpi (8 dots/mm)
Ribbon Support Coated side out
Ribbon Width 1 in to 4.3 in (25.4 mm to 110 mm)
Standard 128 MB Flash, 128 MB SDRAM
Standard Interfaces USB Device, USB Host, factory installed Internal Ethernet
Storage Temperature -40°F to +140°F (-40°C to +60°C)
Type Label Printer
Print Technology Thermal Transfer
Print Speed Up to 4 inches per second
Media Types Supported Roll and fanfold labels, tags, continuous media
Label Roll Capacity Up to 127 mm (5 inch) roll diameter
Dimensions (W x D x H) 205 mm x 172 mm x 159 mm
Weight Approximately 2.5 kg
Power Supply AC Adapter, 100-240V input
Supported Barcodes Code 39, Code 128, EAN-13, UPC-A, Interleaved 2 of 5, QR Code
User Interface LED status indicators and buttons
Emulations EZPL, ZSim, DPL compatible

Key Advantages

These printers provide a compact and lightweight design suitable for limited workspace environments. The thermal transfer technology ensures long-lasting printouts resistant to fading and smudging. Their user-friendly interface simplifies operation and quick media loading. Versatile media handling supports different label sizes and types, increasing application flexibility. Reliable connectivity options enable easy integration into existing IT infrastructure. Additionally, the printers offer consistent print quality with minimal maintenance requirements.

Limitations

The PC300T/PC42E-T models have a print resolution capped at 203 dpi, which may not meet the needs of applications requiring ultra-fine details. Their print speed, while adequate for standard tasks, is lower compared to some high-end industrial printers. Limited advanced connectivity options mean network integration might require additional adapters. The printers lack a color display, reducing interactive user feedback. Media capacity and ribbon length are somewhat limited, impacting long continuous printing runs. They are best suited for small to medium volume printing rather than high-demand industrial environments.

FAQ

The PC42E-T supports various label types including standard paper labels, synthetic labels, and continuous stock suitable for thermal transfer printing.

The PC300T primarily supports USB and serial interfaces; however, network connectivity may require additional network adapters.

Both PC300T and PC42E-T models print at a maximum resolution of 203 dpi.

These models use standard-sized ribbons and labels compatible with common industry specifications to ensure availability and cost-effectiveness.

Yes, they support multiple barcode symbologies, making them suitable for label and barcode printing applications.

No, the PC300T and PC42E-T models do not include a color display screen; they use LED indicators and buttons for basic user interaction.

Printer drivers for these models support major operating systems including Windows, facilitating integration with common office environments.
