Brother QL-1060N
Brand | Brother 2008 |
Model | QL-1060N |
Released Year | 2008 |
Type | Printers |
Status | Discontinued |
Quick view
Overview
The Brother QL-1060N is a professional-grade label printer designed primarily for office and industrial environments requiring high-speed and networked label printing solutions.
It features a fast printing speed of up to 69 labels per minute and supports resolutions up to 300 x 600 dpi for clear and crisp output.
This label printer supports a wide range of label widths up to 60mm, including continuous length labels and die-cut standard size labels, providing versatility for various labeling needs.
Equipped with built-in Ethernet connectivity, the QL-1060N enables easy sharing across multiple users in a networked office setting, streamlining workflow.
Its built-in automatic cutter allows for efficient and precise cutting of labels, reducing manual effort and improving productivity.
The device is also compatible with Brother's P-touch Editor software, which allows customized label creation with fonts, frames, and barcodes.
Specifications
Print Technology | Direct Thermal |
Maximum Print Resolution | 300 x 600 dpi |
Printing Speed | Up to 69 labels per minute |
Label Width | 12 mm to 60 mm |
Connectivity | Serial (RS-232C), USB 1.0/1.1, Ethernet (RJ-45) |
Memory | Built-in Printer Memory |
Label Types Supported | Continuous length, Die-cut labels |
Automatic Cutter | Yes |
Dimensions (WxDxH) | Approximately 183 x 282 x 152 mm |
Weight | Approx. 1.32 kg |
Operating System Compatibility | Windows (limited or no Mac support) |
Power Supply | AC Adapter Included |
Software | Brother P-touch Editor |
MPN | QL-1060N |
UPC | 0012502618812 |
Model | QL-1060N |
Output Type | Black & White |
Platform | M·A·C, Linux, PC Products |
Duplex Printout | Standard |
Extend Printer Technology | Direct Thermal |
Technology | Thermal |
Data Link Protocol | Hippi, Ethernet, Fast Ethernet |
Form Factor | Desktop |
Networking Type | Network Adapter |
Media Type | Photos, Labels, Text, Die-Cut |
Scanner Resolution | 300x300DPI |
Max Resolution (Bw) | 300x300DPI |
Printer Type | Label Printer |
Max Media Size | Roll (0.47in) |
Black Print Speed | 69 Labels/Min |
Images
Key Advantages
The QL-1060N offers fast print speeds, significantly reducing waiting time for label production.
Network functionality via Ethernet makes it suitable for shared office environments.
It supports versatile label sizes and types, enabling diverse labeling applications from shipping to inventory management.
The automatic cutter enhances efficiency and accuracy in label handling.
The high print resolution ensures professional-quality label output with clear text and graphics.
Compatibility with powerful design software facilitates customization and integration with various business processes.
Limitations
The QL-1060N does not support wireless connectivity such as Wi-Fi or Bluetooth, limiting flexible placement options.
Its driver and software compatibility is primarily designed for Windows operating systems, reducing flexibility for Mac or Linux users.
The label roll loading process can be somewhat complex compared to newer models.
It uses thermal printing technology, so it requires thermal labels, potentially limiting label material options.
The printer is relatively bulky and heavier than newer compact models, impacting portability.
Lacks touchscreen interface and modern user-friendly controls, making operation less intuitive for new users.
FAQ
What types of labels does the Brother QL-1060N support?
The Brother QL-1060N supports various labels including standard die-cut labels and continuous length labels up to 60mm wide.
Is the QL-1060N compatible with Mac computers?
The printer is primarily designed for Windows OS and may have limited or no support for Mac operating systems.
Does the QL-1060N support network printing?
Yes, it includes built-in Ethernet connectivity for networked printing.
What is the print resolution of the QL-1060N?
It supports print resolutions up to 300 x 600 dpi for high-quality labels.
Is the Brother QL-1060N still available for purchase?
The Brother QL-1060N has been discontinued, but you may find it through secondary markets or resellers.
What software can I use to design labels for the QL-1060N?
Brother's P-touch Editor software is compatible for designing and printing labels on this device.
Does the printer have a built-in cutter?
Yes, the QL-1060N features an automatic built-in cutter for efficient label output.
