Brother MFC-8480DN image

Brother MFC-8480DN

Quick information
Brand Brother 2006
Model MFC8480DN
Released Year 2006
Type Printers
Series Mfc
Status Discontinued
Quick view

Overview

The Brother MFC-8480DN is a multifunction office printer integrating print, copy, scan, and fax capabilities into a single device. It features a monochrome laser print engine with a maximum print resolution of 1200 x 1200 dpi, delivering sharp and clear documents. This model includes a 33.6 Kbps fax modem supporting various fax protocols such as ECM and broadcasting. It supports Ethernet networking with built-in 10/100 Base-TX connectivity for shared office environments. The scanner offers a flatbed color scanning with an optical resolution of up to 600 x 2400 dpi. The device operates on a 300 MHz processor, coupled with 64 MB RAM (expandable), ensuring efficient multitasking and data processing.

The printer supports multiple operating systems including Windows, Mac OS, and Linux through various drivers such as PCL6 and BR-Script3 emulation. Paper handling comprises a 250-sheet standard input tray plus a 50-sheet multipurpose tray, and a 150-sheet output bin. Duplex printing capability is built-in, reducing paper consumption and improving workflow efficiency. The MFC-8480DN also supports USB 2.0 and parallel port connections for versatile connectivity options. This device is designed to meet small to medium office printing and document handling demands efficiently.

Specifications

MPN MFC8480DN
UPC 0012502622727
Model MFC-8480DN
Technology Laser
Connectivity Ethernet 10/100 Base-TX, USB 2.0, Parallel Port
Output Type Black & White
Type All-In-One Printer
Product Line Brother MFC
Weight approx. 11.8 kg
Height 18.7in
Width 20.91in
Max. Memory 576MB
Platform PC Products
Zoom Range, Reduction 25%,
Extend Printer Technology Laser
Duplex Printout Optional
Installed RAM 64MB
Data Link Protocol Ethernet
Color Black
Direct Printing Capabilities Print Photos Without a PC
Black Copying Speed Up to 32pPM
Scanner Shape Flatbed Scanner
Computer Operating System Microsoft Windows Server 2003x64 Edition, Apple Mac OS X 10.3.9, Microsoft Windows Server 2008
Memory Card Compatibility CompactFlash Type I
Modem Type Fax
Fax Features Supported Automatic Redial, Fax Forward to E-Mail
Form Factor Stationary
Networking Type Network Adapter
Media Type Bond Paper, Transparencies, Plain Paper, Recycled Paper
Scanner Resolution 600 x 2400 dpi optical
Max Resolution (Bw) 1200x1200DPI
Panel Monochrome LCD
Monthly Duty Volume 30000 Pages
Max Media Size Legal (216x356 Mm, 8.5x14in)
Black Print Speed 32ppm
Media Capacity 250 Pages
Print Technology Monochrome Laser
Print Resolution 1200 x 1200 dpi
Print Speed Up to 20 pages per minute
Processor 300 MHz
Memory 64 MB RAM, expandable
Fax Modem Speed 33.6 Kbps
Fax Protocols ECM, Broadcasting, Memory Transmission
Paper Capacity 250-sheet input tray, 50-sheet MP tray, 150-sheet output bin
Duplex Printing Automatic
Operating Systems Windows, Mac OS, Linux
Display 2-line LCD
Dimensions (WxDxH) 403 x 383 x 255 mm

Key Advantages

The Brother MFC-8480DN offers reliable monochrome laser printing with high-resolution output for professional documents. Its multifunction capability consolidates printing, scanning, copying, and faxing, reducing the need for multiple devices. The inclusion of duplex printing saves paper and cuts operational costs. Network connectivity via Ethernet allows multiple users to share the device conveniently in an office environment. Memory expansion options enhance the printer's performance, especially when handling complex print jobs. Additionally, compatibility with major operating systems ensures broad usability and ease of integration.

Limitations

The printer supports monochrome printing only, lacking color print capabilities, which may limit its use for certain business needs. Its fax modem speed is capped at 33.6 Kbps, which is slower compared to newer models with advanced fax technologies. The standard memory of 64 MB may be insufficient for very large or complex printing tasks unless expanded. The scanner's optical resolution maxes at 600 x 2400 dpi, which may not satisfy users requiring very high-resolution color scans. The device design and user interface are somewhat dated, reflecting technology standards from the mid-2000s. Its print speed is moderate, with a typical output of around 20 pages per minute, which might be slow for high-volume printing environments.
