OM SYSTEM Olympus E-PL5
Brand | OM SYSTEM 2012 |
Model | V205040SU000 |
Released Year | 2012 |
Type | Mirrorless Cameras |
Series | E-PL |
Color | Silver |
Compatible Mountings | Micro Four Thirds |
Autofocus | Yes |
Photo Sensor Resolution | 16 MP |
Video Resolution | 1080p |
Optical Zoom | 1 |
File Format | RAW, JPEG, RAW+JPEG, MPO(3D still) |
Status | Discontinued |
Quick view
Overview
The Olympus E-PL5 is a compact mirrorless camera featuring a 16-megapixel Micro Four Thirds Live MOS sensor paired with the TruePic VI image processor, enabling high-quality image capture with low noise levels. It supports ISO sensitivity from 100 to 25600, allowing flexible shooting in varied lighting conditions. The camera comes equipped with a fast autofocus system with 35 focus points, providing quick and accurate subject tracking. It enables Full HD 1080p video recording at 30fps using the AVCHD Lite format. The camera features a 3-inch tiltable touchscreen LCD with approximately 920k dots, enhancing user interaction and composition from various angles. Connectivity options include external flash support, a hot shoe, and compatibility with a wide range of Micro Four Thirds lenses, making it versatile for different photographic needs.
Specifications
Built-In Media | Instruction Manual |
Are Batteries Included | Yes |
Remote Included | No |
UPC | 050332184183 |
Item Height | 2.52 inches |
Manufacturer | Olympus |
Warranty Description | 1 Year Manufacturer |
Connectivity Technology | HDMI, USB |
Wireless Technology | EyeFi |
Total USB 2.0 Ports | 1 |
Total USB Ports | 1 |
Total Video Out Ports | 2 |
Shooting Modes | Scene |
Digital-Still | Yes |
Movie Mode | Yes |
Image Capture Type | Stills & Video |
Night vision | No |
Auto Focus Technology | Continuous, Contrast Detection, Face Detection, Live View, Multi-area, Selective single-point, Single, Touch, Tracking |
Focus Features | Contrast Detection |
Autofocus Points | 35 |
Focus Type | Manual Focus |
Focus Mode | Automatic AF (AF-A) |
Autofocus | Yes |
Aspect Ratio | 4:3 |
File Format | RAW, JPEG, RAW+JPEG, MPO(3D still) |
Effective Still Resolution | 16 MP |
JPEG Quality Level | Fine |
Maximum Image Size | 16 MP |
Bit Depth | 16 Bit |
Total Still Resolution | 16 MP |
Optical Zoom | 1 |
Lens Type | Wide Angle |
Zoom | optical |
Camera Lens | Micro Four Thirds lens system compatible |
Real Angle Of View | 75.1 Degrees |
Metering Methods | Multi, Center-weighted, Spot |
Exposure Control | Aperture priority, Automatic, Program AE, Shutter priority |
White Balance Settings | Flash torch |
Screen Size | 3 Inches |
Display Type | LCD |
Dots Per Screen | 678 |
Display Fixture Type | Tilting |
Touch Screen Type | Yes |
Display Resolution Maximum | 460000 |
Has Color Screen | Yes |
Flash Memory Type | SD/SDHC/SDXC |
Recording Capacity | 60 Minutes |
Write Speed | up to 104 MB/s |
Flash Memory Speed Class | U1 |
Flash Memory UHS Speed Class | 3 |
Flash Memory Video Speed Class | 10 |
Flash Memory Bus Interface Type | UHS-I |
Compatible Mountings | Micro Four Thirds |
Sensor Type | Live MOS |
Image stabilization | Sensor-shift |
Expanded ISO Minimum | 100 |
Photo Sensor Resolution | 16 MP |
Photo Sensor Size | Four Thirds (17.3 x 13 mm) |
Maximum Shutter Speed | 1/4000 Seconds |
Minimum Shutter Speed | 60 seconds |
Form Factor | Mirrorless |
Special Feature | Live View |
Color | Silver |
Item Weight | 0.72 Pounds |
Video Resolution | 1080p |
Viewfinder | No built-in EVF |
Flash Modes | Automatic |
Camera Flash | Built-In |
Skill Level | Professional |
Compatible Devices | Micro Four Thirds |
Continuous Shooting | 8 |
Aperture modes | F2.8-F5.6 |
Flash Sync Speed | 1/250 sec |
Video Capture Format | mpeg-4;h.264;motion_jpeg |
Expanded ISO Maximum | 25600 |
Battery Weight | 0.4 Ounces |
Delay between shots | 0.13 seconds |
Battery Cell Type | Lithium |
Battery Average Life | 360 Photos |
Battery Type | Lithium-Ion BLS-5 rechargeable battery & charger |
Processor Description | truepic 6 |
Water Resistance Level | Not Water Resistant |
Sensor Size | 17.3 x 13.0 mm (Micro Four Thirds) |
Effective Pixels | 16 Megapixels |
Image Processor | TruePic VI |
Lens Mount | Micro Four Thirds |
ISO Sensitivity | 100 - 25600 |
Shutter Speed | 60 - 1/4000 seconds |
Continuous Shooting Speed | Up to 5 fps |
Display | 3.0-inch Tiltable Touchscreen LCD, approx. 920k dots |
Video Recording | Full HD 1080p at 30fps (AVCHD Lite) |
Storage Media | SD, SDHC, SDXC cards |
Flash | Built-in pop-up flash, hot shoe for external flash |
Connectivity | Wi-Fi, USB 2.0 |
Battery | Lithium-ion rechargeable, approx. 320 shots per charge |
Dimensions | 110 x 64 x 38 mm |
Weight | Approximately 334 grams (including battery and memory card) |
Images
Key Advantages
The Olympus E-PL5 excels with a compact and lightweight design that enhances portability and ease of use for everyday photography. Its tiltable touchscreen LCD allows greater flexibility in composing shots from challenging angles. The camera’s 16MP sensor and TruePic VI processor produce sharp and vibrant images with minimal noise. Fast autofocus performance provides reliable focusing, even in dynamic shooting situations. It supports Wi-Fi connectivity for easy image sharing and control via compatible devices. The broad compatibility with Micro Four Thirds lenses and accessories expands creative options for photographers at any skill level.
Limitations
The Olympus E-PL5 lacks a built-in electronic viewfinder, which can make composing images in bright environments challenging. Its continuous shooting speed is limited to around 5 frames per second, which may be insufficient for fast action photography. Battery life is moderate, requiring spares for extended shooting sessions. The camera does not have 4K video recording, limiting video quality compared to more modern models. Low-light autofocus performance can be slower under very dim conditions. The touchscreen, while responsive, is less advanced than current models with gesture controls and higher resolution.
FAQ
What sensor does the Olympus E-PL5 use?
It uses a 16-megapixel Micro Four Thirds Live MOS sensor.
Does the Olympus E-PL5 support video recording?
Yes, it supports Full HD 1080p video recording at 30 frames per second.
Is there a built-in viewfinder on the E-PL5?
No, the E-PL5 does not have a built-in electronic viewfinder.
What type of lenses are compatible with the Olympus E-PL5?
It is compatible with Micro Four Thirds lenses.
Does the camera have Wi-Fi connectivity?
Yes, the Olympus E-PL5 supports Wi-Fi for wireless image transfer and remote control.
What is the ISO range of the E-PL5?
The ISO range extends from 100 to 25600.
Is the screen touch-enabled on the Olympus E-PL5?
Yes, it has a 3-inch tiltable touchscreen LCD.
