Olympus E-PM2
Brand | Olympus 2012 |
Model | V206021BU000 |
Released Year | 2012 |
Type | Mirrorless Cameras |
Series | OM SYSTEM OLYMPUS PEN |
Color | Black |
Compatible Mountings | Micro Four Thirds |
Autofocus | Contrast Detection with 35-area multi AF |
Photo Sensor Resolution | 16 MP |
Video Resolution | FHD 1080p |
Optical Zoom | 3 x |
File Format | RAW, JPEG, RAW+JPEG, MPO(3D still) |
Status | Discontinued |
Quick view
Overview
The Olympus OM SYSTEM OLYMPUS PEN E-PM2 is a compact mirrorless camera utilizing a Micro Four Thirds sensor with 16 megapixels resolution. It features a TruePic VI image processor that enhances image quality and enables fast operation. The camera supports a range of interchangeable lenses through the Micro Four Thirds mount system. Autofocus is achieved via a contrast detection system with multiple AF modes to enhance accuracy. The camera supports Full HD 1080p video recording at multiple frame rates. Its compact design incorporates a built-in flash and multiple connectivity options including USB 2.0 and HDMI output.
The E-PM2’s sensor size of 17.3 x 13 mm provides a balance between image quality and portability. It incorporates Olympus’s standard color filter array to ensure color accuracy. The camera's shutter speed ranges from 60 seconds to 1/4000 second, with an electronic shutter option for silent shooting. It supports ISO sensitivity from 100 to 25600, suitable for low light conditions. The 3.0-inch tilting LCD touchscreen offers user-friendly control and menu navigation with a resolution of approximately 460,000 dots. The E-PM2 is powered by a rechargeable lithium-ion battery, offering approximately 350 shots per charge under CIPA standards.
Specifications
Built-In Media | SD Card |
Are Batteries Included | No |
Remote Included | No |
Global Trade Identification Number | 00050332184336 |
UPC | 050332184336 |
Item Height | 2.52 inches |
Manufacturer | Olympus |
Metering Methods | Multi, Center-weighted, Spot |
Exposure Control | Aperture priority, Automatic, Program AE, Shutter priority |
White Balance Settings | Auto |
Crop Mode | 4:3 |
Screen Size | 3 Inches |
Display Type | LCD |
Dots Per Screen | 460000 |
Display Fixture Type | Fixed |
Touch Screen Type | Yes |
Display Resolution Maximum | 460000 |
Has Color Screen | Yes |
Flash Memory Type | SD/SDHC/SDXC |
Write Speed | 8 fps |
Flash Memory Bus Interface Type | SDIO or SDHCI |
Compatible Mountings | Micro Four Thirds |
Sensor Type | CMOS |
Image stabilization | Sensor-shift |
Maximum Aperture | 3.5 f |
Expanded ISO Minimum | 200 |
Photo Sensor Resolution | 16 MP |
Photo Sensor Size | Micro Four Thirds |
Maximum Shutter Speed | 1/4000 Seconds |
Minimum Shutter Speed | 60 seconds |
Form Factor | Mirrorless |
Special Feature | Image Stabilization |
Color | Black |
Item Weight | 0.59 Pounds |
Video Resolution | FHD 1080p |
Viewfinder | No built-in EVF |
Flash Modes | [Auto, High-Speed Synch/Second Curtain Synch] |
Camera Flash | Built-In |
Skill Level | Professional |
Compatible Devices | Micro Four Thirds |
Continuous Shooting | 8 |
Aperture modes | Aperture priority |
Flash Sync Speed | 1/250 sec |
Video Capture Format | mpeg-4;h.264;motion_jpeg |
Expanded ISO Maximum | 1600 |
Battery Weight | 2 Grams |
Delay between shots | 0.13 seconds |
Battery Cell Type | Lithium Ion |
Battery Average Life | 360 Photos |
Battery Type | Rechargeable Lithium-ion Battery |
Processor Description | truepic 6 |
File Format | RAW, JPEG, RAW+JPEG, MPO(3D still) |
Effective Still Resolution | 16 MP |
JPEG Quality Level | Normal |
Bit Depth | 10 Bit |
Total Still Resolution | 16 MP |
Maximum Focal Length | 84 Millimeters |
Optical Zoom | 3 x |
Lens Type | Standard Zoom |
Zoom | Optical |
Camera Lens | Telephoto lens with a maximum focal length of 84 millimeters |
Minimum Focal Length | 14 Millimeters |
Real Angle Of View | 7.5 Degrees |
Number of Diaphragm Blades | 8 |
Photo Filter Thread Size | 37 Millimeters |
Connectivity Technology | HDMI, USB |
Wireless Technology | EyeFi |
Video Output | HDMI |
Total USB 2.0 Ports | 1 |
Total USB Ports | 1 |
Total Video Out Ports | 1 |
Shooting Modes | Automatic, Shutter Priority, Movie |
Digital-Still | Yes |
Movie Mode | Yes |
Image Capture Type | Stills & Video |
Night vision | No |
Auto Focus Technology | Continuous, Contrast Detection, Face Detection, Live View, Multi-area, Selective single-point, Single, Touch, Tracking |
Focus Features | Contrast Detection |
Autofocus Points | 35 |
Focus Type | Auto Focus |
Focus Mode | Automatic AF (AF-A) |
Autofocus | Contrast Detection with 35-area multi AF |
Model | E-PM2 |
Camera Type | Mirrorless Interchangeable Lens Camera |
Sensor | Micro Four Thirds CMOS |
Effective Pixels | 16 Megapixels |
Sensor Size | 17.3 x 13 mm |
Image Processor | TruePic VI |
Lens Mount | Micro Four Thirds |
ISO Sensitivity | ISO 100–25600 |
Shutter Speed | 60s to 1/4000s (Mechanical), Electronic shutter available |
LCD Screen | 3.0-inch Tilting Touchscreen, approx. 460,000 dots |
Video Recording | Full HD 1080p (30p/25p/24p) |
Flash | Built-in pop-up flash |
Image Stabilization | 3-axis sensor-shift stabilization |
Connectivity | USB 2.0, HDMI output |
Battery Life | Approx. 350 shots (CIPA) |
Dimensions | 110.5 x 64.8 x 34.3 mm |
Weight | Approximately 334 grams (including battery and memory card) |
Images
Key Advantages
The Olympus E-PM2 is highly portable due to its compact body and lightweight design, making it ideal for travel and everyday photography. Its interchangeable Micro Four Thirds lens system offers versatile shooting options with a wide range of compatible lenses. The TruePic VI image processor ensures fast performance and high-quality images. The tilting touchscreen LCD enables flexible shooting angles and easy menu navigation. It offers Full HD video recording capabilities with good image stabilization. Additionally, the camera supports various creative art filters that add unique effects directly in-camera.
Limitations
The Olympus E-PM2 lacks a built-in electronic viewfinder, relying solely on the rear LCD for image composition, which can be challenging in bright light. The autofocus system, being contrast-detection based, may be slower compared to phase-detection systems in some shooting conditions. Battery life is moderate, requiring spare batteries for extended use. The rear LCD resolution is relatively low compared to modern standards. Connectivity options do not include wireless features such as Wi-Fi, limiting remote control and image transfer capabilities. Video recording functionality, while capable, lacks advanced features such as 4K resolution or high frame rates.
FAQ
What type of sensor does the Olympus E-PM2 use?
The Olympus E-PM2 uses a 16 megapixel Micro Four Thirds CMOS sensor measuring 17.3 x 13 mm.
Does the Olympus E-PM2 have a built-in viewfinder?
No, the E-PM2 does not have a built-in electronic viewfinder and relies on the 3.0-inch rear LCD screen for composition.
What lens mount is compatible with the E-PM2?
The camera is compatible with Micro Four Thirds mount lenses, providing access to a wide variety of Olympus and third-party lenses.
Can the E-PM2 record video, and if so, at what quality?
Yes, it can record Full HD 1080p video at frame rates including 30p, 25p, and 24p.
Is there wireless connectivity on the Olympus E-PM2?
No, this model does not feature Wi-Fi or other wireless connectivity options.
What is the battery life of the Olympus E-PM2?
The battery provides approximately 350 shots per charge, based on CIPA testing standards.
Does the E-PM2 have image stabilization?
Yes, the Olympus E-PM2 includes built-in 3-axis sensor-shift image stabilization.
