Nikon 1 AW1
| Brand | Nikon 2013 |
| Model | 27669 |
| Released Year | 2013 |
| Type | Mirrorless Cameras |
| Series | 1 |
| Color | White |
| Compatible Mountings | Nikon 1 |
| Autofocus | Hybrid AF (phase-detection + contrast-detection), 73 focus points |
| Photo Sensor Resolution | 14.2 MP |
| Video Resolution | FHD 1080p |
| Optical Zoom | 2 x |
| File Format | JPEG, Raw (NEF) |
| Status | Discontinued |
Quick view
Overview
The Nikon 1 AW1 is a rugged mirrorless camera introduced in 2013, designed for adventure and underwater photography. It features a 14.2-megapixel CX-format CMOS sensor optimized for high-speed shooting. The camera has an interchangeable lens system with Nikon 1 mount compatibility and comes with waterproof and shockproof construction, allowing use submerged up to 15 meters and impact resistant up to 2 meters. It incorporates a hybrid autofocus system combining phase-detection and contrast-detection technologies for fast and accurate focusing performance. The AW1 supports Full HD 1080p video recording at 60 frames per second and features a bright OLED electronic viewfinder. It includes built-in Wi-Fi for seamless image transfer and remote control functionality, enhancing field usability in challenging environments.
Specifications
| Age Range Description | Adult |
| Built-In Media | AN-N1000 Strap, BF-N2000 Body Cap, EN-EL20 Rechargeable Li-ion Battery, MH-27 Battery Charger, Nikon 1 AW1 Digital Camera with AW 11-27.5mm (White), Nikon View NX 2/Short Movie Creator CD-ROM, PA-N1000 O-ring Protector, Reference Manual CD, UC-E15 USB Cable, User Manual, WP-02000 O-ring Grease |
| Are Batteries Included | Yes |
| External-Memory Size | 64 GB |
| Remote Included | No |
| Series Number | 1 |
| Global Trade Identification Number | 00018208276691 |
| UPC | 018208276691 |
| Item Height | 2.81 inches |
| Manufacturer | Nikon |
| Screen Size | 3 Inches |
| Display Type | LCD |
| Dots Per Screen | 921,000 dots |
| Display Fixture Type | No |
| Touch Screen Type | Capacitive |
| Display Resolution Maximum | 921000 |
| Has Color Screen | Yes |
| Flash Memory Type | SD/SDHC/SDXC card |
| Memory Slots Available | 1 Secure Digital (SD) |
| Memory Storage Capacity | 128 GB |
| Compatible Mountings | Nikon 1 |
| Sensor Type | CMOS |
| Image stabilization | No |
| Maximum Aperture | 3.5 Millimeters |
| Expanded ISO Minimum | 160 |
| Photo Sensor Resolution | 14.2 MP |
| Photo Sensor Size | 1-inch |
| Maximum Shutter Speed | 1/16000 Seconds |
| Minimum Shutter Speed | 30 seconds |
| Form Factor | Mirrorless |
| Special Feature | Waterproof |
| Color | White |
| Item Weight | 7.04 ounces |
| Video Resolution | FHD 1080p |
| Camera Flash | Built-In |
| Skill Level | Professional |
| Continuous Shooting | Up to 15 fps with autofocus |
| Aperture modes | F3.5–F5.6 |
| Audio Input | Built-in microphone (stereo) |
| Flash Sync Speed | 1/60 sec |
| Video Capture Format | AVC |
| Expanded ISO Maximum | 6400 |
| Battery Weight | 40 Grams |
| Audio Output Type | Internal Speaker |
| Battery Cell Type | Lithium Ion |
| Battery Average Life | 220 Photos |
| Battery Type | Lithium-Ion EN-EL20 rechargeable battery & charger |
| Processor Description | EXPEED 3A |
| Water Resistance Level | Waterproof |
| Frame Rate | 15 fps |
| Aspect Ratio | 16:9 |
| File Format | JPEG, Raw (NEF) |
| Effective Still Resolution | 14.2 |
| JPEG Quality Level | Fine |
| Supported Image Format | JPEG, NEF (Nikon's RAW) |
| Total Still Resolution | 14.2 MP |
| Maximum Focal Length | 27.5 Millimeters |
| Optical Zoom | 2 x |
| Camera Lens | AW 11-27.5mm f/3.5-5.6 1 NIKKOR lens |
| Minimum Focal Length | 11 Millimeters |
| Focal Length Description | 11-27.5 millimeters |
| Metering Methods | Multi, Center-weighted, Spot |
| Exposure Control | Aperture priority (A), Automatic, Manual, Program (P), Shutter-priority (S) |
| White Balance Settings | Auto |
| Connectivity Technology | Wi-Fi |
| Wireless Technology | Yes |
| Video Output | HDMI |
| Total USB 2.0 Ports | 1 |
| Total Video Out Ports | 1 |
| Shooting Modes | Automatic, Close-up, Landscape, Night Landscape, Night Portrait, Portrait, Underwater |
| Digital-Still | Yes |
| Movie Mode | Yes |
| Image Capture Type | Stills & Video |
| Night vision | No |
| Auto Focus Technology | Continuous, Contrast Detection, Face Detection, Live View, Multi-area, Phase Detection, Selective single-point, Single, Tracking |
| Focus Features | Hybrid |
| Autofocus Points | 135 |
| Focus Type | Manual Focus |
| Focus Mode | Automatic AF (AF-A) |
| Autofocus | Hybrid AF (phase-detection + contrast-detection), 73 focus points |
| Sensor | 14.2 MP CMOS (CX-format) |
| Image Processor | Expeed 3 |
| ISO Sensitivity | 100-3200 (expandable to 6400) |
| Lens Mount | Nikon 1 mount (interchangeable lenses) |
| Waterproof Rating | 15 meters (50 feet) underwater without housing |
| Shockproof Rating | Drop resistant up to 2 meters |
| Shutter Speed | 30 sec to 1/16,000 sec (electronic shutter) |
| Viewfinder | 0.47" OLED electronic viewfinder with 1,440k dots |
| LCD Screen | 3.0-inch tilting LCD, 921k dots |
| Video Recording | 1080p Full HD at 60 fps |
| Connectivity | Built-in Wi-Fi |
| Dimensions | 113 x 67 x 33 mm |
| Weight | 337 g (with battery and memory card) |
| Battery | Rechargeable EN-EL20 Lithium-ion battery |
| Storage Media | SD/SDHC/SDXC memory cards |
Images
Key Advantages
The Nikon 1 AW1 offers robust waterproofing and shockproof design, making it ideal for underwater and rugged use. Its high-speed autofocus and burst shooting modes facilitate capturing fast-moving subjects effectively. The interchangeable lens system provides flexibility with various Nikon 1 lenses. Lightweight and compact, it is portable for outdoor and adventure activities. The electronic viewfinder delivers a clear preview in bright conditions, outperforming many screen-only mirrorless models. Integrated Wi-Fi enables convenient sharing and remote operation via compatible devices.
Limitations
The 14.2 MP CX sensor provides decent image quality but is smaller than APS-C sensors, which limits low-light performance and dynamic range. Battery life is moderate, requiring spare batteries for extended use. The proprietary Nikon 1 mount has a limited lens selection compared to more established systems. The user interface can be complex for beginners unfamiliar with Nikon's menu system. Video options are constrained to 1080p without 4K support. The rugged design adds some bulk compared to other mirrorless cameras without waterproof features.
FAQ
Is the Nikon 1 AW1 fully waterproof?
Yes, the Nikon 1 AW1 is waterproof up to a depth of 15 meters (50 feet) without any additional housing.
What type of sensor does the Nikon 1 AW1 use?
It uses a 14.2-megapixel CX-format CMOS sensor.
Can I use standard Nikon F-mount lenses with the AW1?
No, the AW1 uses the Nikon 1 mount, which is different from the Nikon F-mount, so standard F-mount lenses are not compatible without an adapter.
Does the Nikon 1 AW1 support 4K video recording?
No, the camera supports Full HD 1080p video recording but does not offer 4K video capabilities.
What are the main rugged features of the Nikon 1 AW1?
It is shockproof up to a 2 meters drop and waterproof up to 15 meters depth, making it suitable for tough environments.
Is there built-in Wi-Fi on the Nikon 1 AW1?
Yes, the camera includes built-in Wi-Fi for wireless image transfer and remote control via compatible devices.
What is the battery life like on the Nikon 1 AW1?
Battery life is moderate; it typically supports around 300 shots per charge, so carrying extra batteries is recommended for extended use.
