Lenovo ThinkPad X1 Carbon Gen 12
| Brand | Lenovo 2024 |
| Model | Ultra 7 155U, WUXGA Touch |
| Released Year | 2024 |
| Type | Laptop |
| Screen Resolution | 1920 x 1200 pixels |
| Color | Black |
| Processor | Intel 13th Gen Core i5 / i7 / i7 vPro up to 14 cores (6P + 8E cores) |
| RAM | 32 GB LPDDR5X |
| Hard Drive | 1 TB SSD |
| Graphics Coprocessor | Integrated Intel Graphics |
| Chipset Brand | Intel |
| Status | Active |
Quick view
Overview
The Lenovo ThinkPad X1 Carbon Gen 12 is a premium ultrabook designed for professional use, featuring the latest 13th Generation Intel Core processors with up to 14 cores leveraging Intel's hybrid architecture.
It includes a 14-inch WUXGA (1920 x 1200) touch display panel with anti-reflective and anti-smudge coatings, providing enhanced visual clarity and responsiveness.
The chassis is constructed with carbon fiber and magnesium alloy, delivering a lightweight yet durable build weighing approximately 1.12 kg.
Memory options include up to 32GB LPDDR5 RAM soldered onto the motherboard, supporting fast data processing and efficient multitasking.
Storage is provided via PCIe Gen4 NVMe SSDs, configurable up to 2TB, enabling high-speed data access and boot times.
The device integrates Wi-Fi 6E and optional 5G WWAN connectivity, along with Thunderbolt 4 ports for versatile and high-speed peripheral connectivity.
Specifications
| Standing screen display size | 14 Inches |
| Screen Resolution | 1920 x 1200 pixels |
| Max Screen Resolution | 1920x1200 Pixels |
| Processor | Intel 13th Gen Core i5 / i7 / i7 vPro up to 14 cores (6P + 8E cores) |
| RAM | 32 GB LPDDR5X |
| Memory Speed | 6400 MHz |
| Hard Drive | 1 TB SSD |
| Graphics Coprocessor | Integrated Intel Graphics |
| Chipset Brand | Intel |
| Card Description | Integrated |
| Wireless Type | Bluetooth |
| Number of USB 3.0 Ports | 2 |
| Series | ThinkPad X1 Carbon Gen 12 |
| Item model number | Ultra 7 155U, WUXGA Touch |
| Operating System | Windows 11 Pro / Home |
| Item Weight | 2.4 pounds |
| Product Dimensions | 0.59 x 8.45 x 12.31 inches |
| Item Dimensions LxWxH | 0.59 x 8.45 x 12.31 inches |
| Color | Black |
| Processor Brand | Intel |
| Number of Processors | 12 |
| Computer Memory Type | DDR5 RAM |
| Flash Memory Size | 1 TB |
| Hard Drive Interface | Serial ATA-600 |
| Optical Drive Type | No Optical Drive |
| Power Source | Battery Powered |
| Batteries | 1 Lithium Polymer batteries required. (included) |
| Date First Available | August 9, 2024 |
| Display | 14-inch WUXGA (1920 x 1200) IPS Touchscreen, Anti-reflective, Anti-smudge |
| Graphics | Integrated Intel Iris Xe Graphics |
| Memory | Up to 32GB LPDDR5 5200MHz (soldered) |
| Storage | PCIe Gen 4 NVMe SSD up to 2TB |
| Connectivity | Wi-Fi 6E (802.11ax), Optional 5G WWAN, Bluetooth 5.2 |
| Ports | 2 x Thunderbolt 4, 2 x USB 3.2 Gen 1 Type-A, HDMI 2.0, Audio jack |
| Battery | 57Wh Lithium-Polymer, Rapid Charge support |
| Dimensions | 313.6mm x 221.2mm x 14.9mm |
| Weight | Starting at 1.12 kg (2.48 lbs) |
| Security | Fingerprint reader, IR camera for Windows Hello, Webcam privacy shutter |
| Chassis Material | Carbon Fiber and Magnesium Alloy |
| Keyboard | Backlit keyboard with TrackPoint and Precision touchpad |
| Audio | Dolby Atmos Speaker System, Dual far-field microphones |
| Webcam | 720p HD with privacy shutter |
Images
Key Advantages
The ThinkPad X1 Carbon Gen 12 offers exceptional portability due to its slim profile and low weight, ideal for frequent travelers and professionals.
Its high-performance Intel 13th Gen CPUs combined with LPDDR5 RAM ensure powerful computing capabilities for demanding applications.
The WUXGA display with touch support enhances usability while maintaining excellent screen brightness and color accuracy.
Robust security features include a fingerprint reader, IR camera with Windows Hello, and a privacy shutter for the webcam.
Long battery life is supported with rapid charging technology, enabling extended usage on the go.
Military-grade durability certifications ensure reliability in various working environments.
Limitations
The device's integrated graphics are limited for heavy gaming or high-end graphical workloads compared to dedicated GPUs.
RAM is soldered and non-upgradable, limiting post-purchase memory expansion.
Relatively high price point can be a barrier for budget-conscious buyers.
The screen resolution maxes out at WUXGA, lacking 4K or OLED options in this configuration.
Thunderbolt 4 ports are versatile but limited in number, so users may require adapters for multiple devices.
Webcam resolution remains at 720p, which might be less ideal for professional video conferencing requiring higher definition.
FAQ
What processors are available in the ThinkPad X1 Carbon Gen 12?
It features 13th Generation Intel Core processors with hybrid architecture, offering up to 14 cores for improved performance and efficiency.
Does the ThinkPad X1 Carbon Gen 12 support touchscreen functionality?
Yes, the selected model includes a 14-inch WUXGA touchscreen with anti-reflective and anti-smudge coatings.
Is the RAM upgradable in this laptop?
No, the RAM is soldered onto the motherboard and cannot be upgraded after purchase.
What type of storage does this laptop use?
It uses PCIe Gen4 NVMe SSDs, configurable up to 2TB for fast and reliable storage.
What connectivity options does this model provide?
Wi-Fi 6E, optional 5G WWAN, multiple Thunderbolt 4 ports, USB-A ports, and HDMI output are available.
Is the battery replaceable by the user?
The battery is internal and not user-removable, but Lenovo provides authorized service options for replacement.
Does this model have built-in security features?
Yes, it includes a fingerprint reader, IR camera for facial recognition, and a physical webcam privacy shutter.
