OM SYSTEM EVOLT E-420
Brand | OM SYSTEM 2007 |
Model | 262082 |
Released Year | 2007 |
Type | DSLR Cameras |
Series | Evolt |
Compatible Mountings | Four Thirds |
Autofocus | Yes |
Photo Sensor Resolution | 10 MP |
Video Resolution | 720p |
Optical Zoom | 1 |
File Format | RAW |
Status | Discontinued |
Quick view
Overview
The OM SYSTEM EVOLT E-420 is a compact digital single-lens reflex (DSLR) camera introduced in 2007. It features a 10-megapixel Live MOS Sensor which captures high-resolution images with precision. The camera incorporates the Four Thirds System mount, ensuring compatibility with a wide range of lenses. It offers a fast autofocus system with 3-point TTL autofocus sensors for accurate focusing. The camera supports various exposure modes including manual, aperture priority, and shutter priority, providing flexibility for different shooting conditions. The E-420 includes an optical TTL viewfinder with approximately 95% frame coverage and a 2.5-inch LCD screen for image review and menu navigation.
Advanced image processing is handled by Olympus’s TruePic Turbo engine, delivering fine detail and color reproduction. It has a continuous shooting speed of up to 3 frames per second, catering to moderate action photography needs. ISO sensitivity ranges from 100 to 1600, expandable in some modes, balancing noise and dynamic range. The camera uses CompactFlash cards for image storage and supports RAW and JPEG formats. It features built-in dust reduction technology to maintain image quality in various environments. Additionally, the EVOLT E-420 provides comprehensive manual controls alongside automatic modes to suit both amateur and enthusiast photographers.
Specifications
Age Range Description | Kid |
Built-In Media | Camera Body & Lens |
Are Batteries Included | Yes |
Remote Included | No |
Global Trade Identification Number | 00050332163911 |
UPC | 050332163911 |
Item Height | 3.58 inches |
Manufacturer | Olympus |
Screen Size | 2.7 Inches |
Display Type | LCD |
Display Fixture Type | Fixed |
Display Resolution Maximum | 230,000 |
Has Color Screen | Yes |
Flash Memory Type | Compact Flash (Type I or II), xD Picture Card |
Write Speed | 3.5 fps |
Compatible Mountings | Four Thirds |
Sensor Type | Live MOS |
Image stabilization | Digital, Dynamic, Optical |
Maximum Aperture | 2.8 f |
Photo Sensor Resolution | 10 MP |
Photo Sensor Size | 1.5 |
Maximum Shutter Speed | 1/4000 Seconds |
Minimum Shutter Speed | 60 seconds |
Form Factor | Compact SLR |
Special Feature | Lightweight |
Item Weight | 0.94 Pounds |
Video Resolution | 720p |
Viewfinder | Optical TTL, approx. 95% frame coverage |
Flash Modes | Auto, On/Fill, Off |
Camera Flash | Built-In |
Compatible Devices | Computers, storage devices (CompactFlash, Microdrive, xD-Picture Card) |
Continuous Shooting | 3 fps |
Aperture modes | F2.8 |
Viewfinder Magnification | 0.92x |
Flash Sync Speed | 1/4000_sec |
Video Capture Format | MP4 |
Battery Weight | 80 Grams |
Battery Cell Type | Lithium Ion |
Battery Type | Lithium Ion |
Processor Description | TruePic III |
Water Resistance Level | Not Water Resistant |
Frame Rate | 30 fps |
Mount Type | Four Thirds |
Item Dimensions D x W x H | 2.1"D x 5.1"W x 3.6"H |
Minimum Aperture | 2.8 |
File Format | RAW |
Effective Still Resolution | 10 MP |
JPEG Quality Level | Fine |
Maximum Focal Length | 25 Millimeters |
Optical Zoom | 1 |
Lens Type | Fixed Focal Length |
Zoom | Optical and Digital Zoom |
Camera Lens | 25mm f/2.8 Pancake Zuiko Lens |
Minimum Focal Length | 25 Millimeters |
Real Angle Of View | 28.6 Degrees |
Metering Methods | Spot |
Exposure Control | Automatic, Manual, Program, aperture-priority, bulb, shutter-priority |
White Balance Settings | Auto |
Connectivity Technology | USB |
Wireless Technology | Yes |
Total USB 2.0 Ports | 1 |
Shooting Modes | Landscape, Macro, Night Portrait, Panorama, Portrait, Sports, beach/snow, candle, children, document, fireworks, high key, landscape-portrait, low key, nature macro, sunset, underwater macro, underwater wide |
Digital-Still | Yes |
Movie Mode | No |
Image Capture Type | Stills |
Auto Focus Technology | Continuous, Contrast Detection, Live View, Multi-area, Phase Detection, Selective single-point |
Focus Features | 3-point TTL Phase Diff, 11-point TTL Contrast Detect |
Autofocus Points | 3 |
Focus Type | Autofocus & Manual |
Focus Mode | Continuous-Servo AF (AF-C) |
Autofocus | Yes |
Release Year | 2007 |
Camera Type | Digital SLR |
Sensor Size | 17.3 x 13.0 mm (Four Thirds System) |
Effective Pixels | 10 Megapixels |
Lens Mount | Four Thirds |
Focus System | 3-point TTL contrast-detect autofocus |
Exposure Modes | Manual, Aperture Priority, Shutter Priority, Program Auto |
Shutter Speed Range | 1/4,000 sec to 60 sec |
ISO Sensitivity | 100 - 1600 |
LCD Monitor | 2.5 inch TFT LCD, approx. 215,000 pixels |
Storage Media | CompactFlash Type I and II |
Image Formats | RAW (ORF), JPEG |
White Balance | Auto, presets, and manual adjustment |
Flash | Built-in pop-up and hot shoe for external flash |
Battery | Li-ion rechargeable battery |
Dimensions | 124 x 86 x 45 mm |
Weight | Approx. 380 g (body only) |
Dust Reduction | Supersonic Wave Filter |
Connectivity | USB 2.0 |
Images
Key Advantages
The OM SYSTEM EVOLT E-420 boasts a lightweight and compact design, making it highly portable and comfortable for extended use. Its 10-megapixel Live MOS sensor delivers sharp, high-quality images with vibrant colors and excellent detail. Compatibility with Four Thirds lenses opens a versatile range of optical options for different shooting styles. The camera’s autofocus system is responsive and precise, enhancing subject tracking and composition accuracy. TruePic Turbo image processing ensures fast operation and improved image quality even in lower light. The inclusion of dust reduction technology helps maintain sensor cleanliness, reducing the need for frequent manual cleaning.
Limitations
The EVOLT E-420’s 3-point autofocus system, while effective, is basic compared to more contemporary DSLRs that offer multi-point or cross-type AF systems. Its 2.5-inch LCD screen, by modern standards, provides limited resolution and no live view capability. The ISO range tops out at 1600, which may limit performance in very low light situations with higher noise levels. The camera’s continuous shooting speed of 3 frames per second is moderate but may not suffice for high-speed or professional sports photography. Lack of video recording functionality restricts use for multimedia purposes common in newer models. Additionally, the utilization of CompactFlash cards can be considered outdated and less convenient compared to SD card formats currently favored.
FAQ
What sensor type does the EVOLT E-420 use?
The EVOLT E-420 uses a 10-megapixel Live MOS sensor with a Four Thirds System size.
Does the camera support manual exposure controls?
Yes, the EVOLT E-420 supports manual, aperture priority, shutter priority, and program auto exposure modes.
Can the EVOLT E-420 shoot video?
No, this model does not have video recording capabilities.
What types of memory cards does the EVOLT E-420 use?
It uses CompactFlash Type I and II cards for storage.
Is the EVOLT E-420 still in production?
No, this model has been discontinued.
What is the maximum ISO sensitivity available on this camera?
The ISO range extends up to 1600.
Does the EVOLT E-420 include any dust reduction features?
Yes, it incorporates a supersonic wave filter for dust reduction on the sensor.
