OM SYSTEM EVOLT E-300
Brand | OM SYSTEM 2006 |
Model | 262051 |
Released Year | 2006 |
Type | DSLR Cameras |
Series | E-300 |
Compatible Mountings | Four Thirds |
Autofocus | TTL contrast-detection AF |
Photo Sensor Resolution | 8 MP |
Video Resolution | 720p |
Optical Zoom | 3.2 |
File Format | JPEG, RAW |
Status | Discontinued |
Quick view
Overview
The OM SYSTEM EVOLT E-300 is a digital single-lens reflex (DSLR) camera introduced in 2006, featuring a 8.0-megapixel Live MOS sensor that delivers high-quality images with good color fidelity and low noise. It utilizes the Four Thirds system lens mount, allowing compatibility with a wide range of Four Thirds lenses for versatile shooting options. The camera supports a maximum resolution of 3264 x 2448 pixels and offers both RAW and JPEG image capture formats for professional-level post-processing flexibility.
Equipped with a TTL (Through The Lens) contrast-detection autofocus system, the EVOLT E-300 facilitates accurate focusing, especially suitable for still subjects. Its shutter speed range spans from 60 seconds to 1/4000 second, accommodating both long-exposure and fast-action photography. The camera incorporates a built-in pop-up flash and supports external flashes through a hot shoe for extended lighting possibilities. Power is supplied via a rechargeable lithium-ion battery, providing reliable shooting duration for field use.
Specifications
Built-In Media | Battery, Battery Charger, Instruction Manual, Remote, Shoulder Strap, USB Cable, Warranty Card |
Are Batteries Included | No |
Remote Included | No |
Global Trade Identification Number | 00050332149014 |
UPC | 050332149014 |
Item Height | 3.35 inches |
Manufacturer | Olympus |
Exposure Control | Automatic, Manual, Program, aperture-priority, bulb, shutter-priority |
White Balance Settings | Auto |
Self Timer | 1E+1, 2, 5 |
Screen Size | 1.8 Inches |
Display Type | LCD |
Dots Per Screen | [High] |
Display Fixture Type | Fixed |
Display Resolution Maximum | 134,000 |
Has Color Screen | Yes |
Flash Memory Type | Compact Flash |
Write Speed | 2.5 fps |
Flash Memory Bus Interface Type | Parallel ATA (PATA) |
Flash Memory Supported Size Maximum | 32 GB |
Compatible Mountings | Four Thirds |
Sensor Type | Live MOS |
Image stabilization | Digital, Optical |
Maximum Aperture | 3.5 f |
Photo Sensor Resolution | 8 MP |
Photo Sensor Size | 1.5 |
Maximum Shutter Speed | 1/4000 Seconds |
Minimum Shutter Speed | 60 seconds |
Form Factor | Mid-size SLR |
Item Weight | 1.38 Pounds |
Video Resolution | 720p |
Viewfinder | Optical pentaprism |
Flash Modes | Automatic |
Camera Flash | Built-In |
Compatible Devices | Four Thirds lenses and Compact Flash memory devices |
Continuous Shooting | 2.5 |
Aperture modes | F3.5–F5.6 |
Flash Sync Speed | 1/4000_sec |
Video Capture Format | MP4 |
Expanded ISO Maximum | 1600 |
Battery Weight | 1 Grams |
Delay between shots | 0.4 seconds |
Battery Cell Type | Lithium Ion |
Guide Number | 15 |
Battery Type | Lithium Ion |
Water Resistance Level | Not Water Resistant |
Frame Rate | 30 FPS |
Mount Type | Four Thirds |
Crop Factor | 2 |
Mounting Thread Type | Bayonet mount, 30.5mm diameter, 1.0mm pitch |
File Format | JPEG, RAW |
Effective Still Resolution | 8 MP |
JPEG Quality Level | Fine |
Bit Depth | 24 Bit |
Total Still Resolution | 8 MP |
Maximum Focal Length | 45 Millimeters |
Optical Zoom | 3.2 |
Lens Type | Four Thirds |
Zoom | Optical Zoom |
Camera Lens | The camera is compatible with the Zuiko Digital 40-150mm (80-300mm) lens with a variable aperture of f3.5-4.5, indicating a versatile lens suitable for various shooting scenarios, including telephoto and portrait photography. |
Minimum Focal Length | 45 Millimeters |
Real Angle Of View | 28.54 Degrees |
Number of Diaphragm Blades | 7 |
Lens Construction | Four Thirds |
Connectivity Technology | USB |
Wireless Technology | usb |
Video Output | HDMI |
Total USB Ports | 1 |
Total Video Out Ports | 1 |
Shooting Modes | Landscape, Macro, Night Portrait, Portrait, Sports, beach/snow, candle, document, fireworks, high key, landscape-portrait, manor shot, self-portrait, sunset |
Digital-Still | Yes |
Movie Mode | Yes |
Image Capture Type | Stills & Video |
Night vision | No |
Auto Focus Technology | Continuous, Multi-area, Phase Detection, Selective single-point, Single |
Focus Features | 3-point TTL Phase Diff |
Autofocus Points | 3 |
Focus Type | Autofocus & Manual |
Focus Mode | Continuous-Servo AF (AF-C) |
Autofocus | TTL contrast-detection AF |
Model | EVOLT E-300 |
Release Year | 2006 |
Camera Type | Digital SLR |
Sensor Size | Four Thirds (17.3 x 13 mm) |
Effective Resolution | 8.0 Megapixels |
Image Resolution | 3264 x 2448 pixels |
Lens Mount | Four Thirds system |
Shutter Speed Range | 60 sec to 1/4000 sec |
ISO Sensitivity | 100 - 1600 |
Flash | Built-in pop-up flash, hot shoe for external flash |
LCD Screen | 1.8-inch TFT LCD |
Storage Media | CF (CompactFlash) Type I/II cards |
Image Formats | RAW, JPEG |
Battery | Rechargeable lithium-ion battery |
Dimensions | 130 x 88 x 67 mm |
Weight | Approx. 495g (body only) |
Video Recording | No |
Images
Key Advantages
The OM SYSTEM EVOLT E-300 offers excellent image quality with its 8-megapixel sensor, which was competitive for its time. Its compatibility with Four Thirds lenses provides users with extensive lens options tailored to different photography styles.
The camera's compact and lightweight body design enhances portability without compromising on DSLR features. The inclusion of RAW image capture supports advanced editing workflows favored by enthusiasts and semi-professionals.
The TTL contrast-detection autofocus provides precise focusing performance, and the broad shutter speed range allows creative flexibility in various lighting conditions.
Limitations
The contrast-detection autofocus system, while accurate, is slower compared to phase-detection systems found in more advanced DSLRs, limiting fast-action photography performance. The 8-megapixel resolution, though adequate in 2006, may be considered low by modern standards.
Its ISO range is relatively narrow (100-1600), potentially limiting low-light shooting capability. The rear LCD screen has modest resolution and size, which could affect image reviewing and menu navigation ease.
No live view function is offered, and video recording capabilities are absent, reflecting its focus on still photography and the technological limits at its release time.
FAQ
What type of sensor does the OM SYSTEM EVOLT E-300 use?
It uses an 8.0-megapixel Live MOS Four Thirds sensor.
Which lens mount does the EVOLT E-300 support?
The camera supports the Four Thirds system lens mount.
Does the EVOLT E-300 have video recording capabilities?
No, the EVOLT E-300 is designed only for still photography and does not support video recording.
What is the shutter speed range of the EVOLT E-300?
The shutter speed ranges from 60 seconds to 1/4000 second.
Can the OM SYSTEM EVOLT E-300 shoot RAW images?
Yes, it supports RAW and JPEG image formats.
What kind of autofocus system is used in the EVOLT E-300?
It uses a TTL contrast-detection autofocus system.
Is the OM SYSTEM EVOLT E-300 still in production?
No, this model has been discontinued.
