OM SYSTEM OM-D E-M5
Brand | OM SYSTEM 2012 |
Model | FBA_OM-D - Black Kit |
Released Year | 2012 |
Type | DSLR Cameras |
Series | OM-D |
Color | Black |
Compatible Mountings | Micro Four Thirds |
Autofocus | Yes |
Photo Sensor Resolution | 16 MP |
Video Resolution | 1080p |
Optical Zoom | 4.2 |
File Format | JPEG, RAW |
Status | Discontinued |
Quick view
Overview
The OM-D E-M5 is a mirrorless interchangeable lens camera combining the compactness of a micro four thirds system with DSLR-like handling. It features a 16.1 megapixel Live MOS sensor and the TruePic VI image processor that delivers high-resolution images with low noise. The camera incorporates a 5-axis image stabilization system to minimize blur from camera shake across multiple movement axes. Autofocus is powered by contrast-detection with 81 focus points helping fast and accurate subject acquisition. The electronic viewfinder has a 1.44 million dot resolution providing clear and detailed framing information. It supports full HD 1080p video recording and offers numerous creative shooting modes.
Specifications
Built-In Media | Camera Body & Lens |
Are Batteries Included | Yes |
Remote Included | No |
UPC | 017896523377 |
Item Height | 8.89 centimeters |
Manufacturer | Olympus |
Exposure Control | Automatic |
Screen Size | 3 Inches |
Display Type | OLED |
Display Fixture Type | Tilting |
Display Resolution Maximum | 16.1 MP |
Has Color Screen | Yes |
Flash Memory Type | SDXC |
Write Speed | 9 fps |
Compatible Mountings | Micro Four Thirds |
Sensor Type | Live MOS |
Image stabilization | Optical |
Expanded ISO Minimum | 200 |
Photo Sensor Resolution | 16 MP |
Photo Sensor Size | 1 |
Maximum Shutter Speed | 60 Seconds |
Form Factor | Compact |
Special Feature | Interchangable Lens |
Color | Black |
Item Weight | 425 Grams |
Video Resolution | 1080p |
Viewfinder | Electronic Viewfinder, 1.44 million dots |
Flash Modes | Auto, On/Fill, Off |
Camera Flash | no flash |
Compatible Devices | Computers, smartphones, tablets, external storage devices |
Continuous Shooting | 9 |
Aperture modes | F3.5-F22 |
Flash Sync Speed | 1/250_sec |
Video Capture Format | h.264;motion_jpeg |
Expanded ISO Maximum | 25600 |
Battery Type | Lithium Ion |
Water Resistance Level | Not Water Resistant |
Frame Rate | 30 FPS |
Mount Type | Micro Four Thirds |
Waterproof Rating | なし |
Microphone Technology | Stereo |
Minimum Aperture | 3.5 |
Crop Factor | 2 |
Number of Batteries | 1 Lithium Ion batteries required. (included) |
Aspect Ratio | 4:3 |
File Format | JPEG, RAW |
Effective Still Resolution | 16.1 |
JPEG Quality Level | Fine |
Total Still Resolution | 16 MP |
Maximum Focal Length | 50 Millimeters |
Optical Zoom | 4.2 |
Lens Type | Zoom |
Zoom | Optical and Digital Zoom |
Camera Lens | 12-50mm lens with image stabilization |
Minimum Focal Length | 12 Millimeters |
Digital Zoom | 4 x |
Photo Filter Thread Size | 52 Millimeters |
Connectivity Technology | HDMI, USB |
Wireless Technology | Wi-Fi |
Total USB 2.0 Ports | 1 |
Total USB Ports | 1 |
Digital-Still | Yes |
Movie Mode | Yes |
Image Capture Type | Stills & Video |
Auto Focus Technology | Contrast Detection |
Focus Features | Hybrid |
Autofocus Points | 81 contrast-detection points |
Focus Type | Automatic with manual |
Autofocus | Yes |
Model | OM-D E-M5 |
Release Year | 2012 |
Camera Type | Mirrorless Interchangeable Lens Camera |
Sensor Size | 17.3 x 13 mm (Micro Four Thirds) |
Effective Megapixels | 16.1 MP |
Image Processor | TruePic VI |
Image Stabilization | 5-axis in-body image stabilization |
Screen | 3-inch Vari-angle LCD, approx. 610k dots |
ISO Sensitivity | ISO 200 - 25600 |
Shutter Speed | 60s to 1/4000s |
Continuous Shooting Speed | Up to 9 fps |
Video Recording | Full HD 1080p at 30fps |
Flash | Built-in Pop-up Flash |
Connectivity | Wi-Fi 802.11b/g/n |
Battery Life | Approx. 330 shots (CIPA) |
Dimensions | 124.9 x 85.2 x 45.2 mm |
Weight | Approximately 425g (body only) |
Lens Mount | Micro Four Thirds |
Images
Key Advantages
The OM-D E-M5 provides a highly effective 5-axis image stabilization system that benefits both still photography and video capture by compensating for multiple types of camera movement. Its compact and lightweight magnesium alloy body is durable and weather sealed for professional-level use in various conditions. The advanced autofocus system with 81 points ensures quick and reliable focusing performance. The high-resolution electronic viewfinder mimics the experience of an optical viewfinder with real-time display advantages. The camera's sensor and image processor combination delivers excellent image quality and fine detail even in low light. It also offers built-in Wi-Fi connectivity for seamless image sharing and remote control.
Limitations
Despite its strengths, the OM-D E-M5's micro four thirds sensor is smaller than APS-C or full-frame sensors, limiting depth of field control and wide dynamic range compared to larger sensor cameras. The electronic shutter may introduce rolling shutter artifacts during fast action or under certain artificial lighting. Battery life is moderate, typically requiring spares for extended shooting sessions. The autofocus system, while good, is contrast-based and can be slower in continuous tracking compared to phase-detection systems. Some users may find the menu system complex to navigate initially. Additionally, the camera's video capabilities, while capable, lack some advanced features found in newer models.
FAQ
What sensor size does the OM-D E-M5 have?
The OM-D E-M5 uses a Micro Four Thirds 16.1-megapixel Live MOS sensor.
Does the OM-D E-M5 have image stabilization?
Yes, it features a 5-axis in-body image stabilization system that compensates for camera shake.
Is the OM-D E-M5 weather sealed?
The camera body is magnesium alloy and weather sealed to resist dust and moisture.
What kind of viewfinder does the OM-D E-M5 use?
It has a 1.44 million dot electronic viewfinder with real-time preview capabilities.
Can the OM-D E-M5 record video?
Yes, it supports Full HD 1080p video recording with various frame rates.
Is the autofocus system fast for action photography?
It has 81 contrast-detection autofocus points which are effective but can be slower than phase-detection autofocus in some scenarios.
Does the camera support wireless connectivity?
Yes, it includes built-in Wi-Fi for remote control and image transfer.
