Olympus E-PL5 image

Olympus E-PL5

Quick information
Brand Olympus 2012
Model V205041BU010
Released Year 2012
Type Digital Cameras
Series Pen
Color Black
Autofocus Contrast-detection AF system
Status Discontinued
Quick view

Overview

The Olympus PEN E-PL5 is a mirrorless digital camera launched in 2012 as part of the PEN series, featuring a compact Micro Four Thirds interchangeable lens system. It is equipped with a 16.1-megapixel Live MOS sensor which delivers high-resolution images with excellent detail and color accuracy. The camera incorporates a TruePic VI image processor, enhancing performance speed and image processing efficiency. It supports a maximum ISO sensitivity of 12800, allowing for better low-light photography. Autofocus is achieved via contrast-detection with multiple AF modes, supporting quick and accurate focusing. The E-PL5 includes a 3-inch tilting LCD screen with 460k dots for flexible composition, but lacks a built-in electronic viewfinder.

Specifications

MPN V205041BU010
UPC 0050332184206
Model E-PL5
Digital Zoom 2x
Color Black
Battery Type Lithium-Ion
Connectivity USB 2.0, HDMI
Features 16:9 Widescreen Mode, 1080i Full HD Movie Recording, USB, DPOF Support, Hdmi
Series Olympus PEN
Type Digital SLR
Depth 1.5in
Height 2.5in
Width 4.4in
Item Weight 9.8 Oz.
Red Eye Reduction Yes
Focal Length Range 14mm-42mm
Light Sensitivity Iso Auto (200-25600), Iso 200-25600
Sensor Type Live MOS
Lens Type Zoom Lens
Sensor Resolution 16.1MP
Additional Features 16:9 Widescreen Mode, 1080i Full HD Movie Recording, USB, Dpof Support, Hdmi
Flash Type Detachable Flash
Face Detection Yes
Special Effects Monotone, Light Tone, Pop Art, I-Enhance, Portrait, Pale & Light Colour, Water Colour, Diorama, Natural, Pin Hole, Grainy Film, Soft Focus, Vivid, Gentle Sepia, Cross Process, Dramatic Tone, Custom Effect, Muted
Battery Form Factor Manufacturer Specific
Sensor Size 17.3 x 13 mm (Micro Four Thirds)
Display Size 3in
Still Image Format Raw + JPEG, Raw, JPEG, Mpo
Exterior Color Black
Display Rotation Folding
Shooting Programs Landscape-Portrait, Portrait Mode, Landscape, Nature Macro, Fisheye Converter, E-Portrait, Macro Converter, Document, High Key, Beach/Snow, Low Key, Night Scene with Portrait, Sports Mode, Night Scene, Children, Fireworks, Panorama Assist
Digital Video Format Avi, Mov, H.264, Mjpeg
Screen Size 3.0"in
Light Sensitivity Max 25600
Camera Type Digital SLR
Maximum Resolution 16.1MP
Viewfinder Type None
Lens for Sd II R 14-42mm
Supported Flash Memory SDHC Memory Card, SDXC Memory Card, SD Memory Card
Megapixels 16.1 effective megapixels
Image Processor TruePic VI
Lens Mount Micro Four Thirds mount
ISO Sensitivity Auto, 100-12800
Autofocus Contrast-detection AF system
Shutter Speed Range 1/4000 to 60 seconds
Continuous Shooting Speed Up to 8 fps
Viewfinder No built-in EVF
LCD Screen 3-inch tilting LCD, 460k dots
Image Stabilization In-body 3-axis image stabilization
Video Recording 1080p Full HD at 30fps
Storage Media SD/SDHC/SDXC card slot
Battery BLN-1 Lithium-ion rechargeable battery
Dimensions 113 x 64 x 38 mm
Weight Approximately 332 grams (body only)

Key Advantages

The Olympus PEN E-PL5 is notable for its compact and lightweight design, making it highly portable for photographers on the move. It offers high image quality with its 16.1MP sensor and the advanced TruePic VI processor. The tilting LCD screen enhances usability, especially for low or high-angle shots. Its compatibility with the diverse Micro Four Thirds lens ecosystem provides versatility across photography styles. Built-in image stabilization in the body minimizes shake and facilitates sharper handheld shots. Additionally, it supports various advanced shooting modes and creative filters to enrich photographic expression.

Limitations

The Olympus PEN E-PL5 lacks a built-in electronic viewfinder, which could be a drawback for users preferring eye-level composition. The autofocus system, while effective, is contrast-detection based and may be slower compared to phase-detection systems in some scenarios. Its maximum continuous shooting speed is moderate, limiting rapid action capture. Battery life is average, requiring extra batteries for extensive use. Video recording is limited to 1080p Full HD without advanced features. The camera does not have wireless connectivity options like Wi-Fi or Bluetooth natively, limiting instant sharing capabilities.
