Olympus D-535 Zoom
| Brand | Olympus 2002 |
| Model | D-535 ZOOM, 225515 |
| Released Year | 2002 |
| Type | Digital Cameras |
| Series | Camedia |
| Optical Zoom | 3x |
| Status | Discontinued |
Quick view
Overview
The Olympus Camedia D-535 Zoom is a compact digital camera introduced in 2002, featuring a 3.2-megapixel CCD sensor that captures images at a maximum resolution of 2048 x 1536 pixels.
It is equipped with a 3x optical zoom lens, allowing for moderate telephoto photography with focal length equivalent to 38-114mm in 35mm format.
The camera includes a built-in flash, manual and automatic exposure modes, and an electronic viewfinder alongside an LCD screen for framing shots.
Image storage is facilitated via SmartMedia cards with support for various capacities, and the camera connects to computers via USB interface for easy file transfer.
The D-535 Zoom offers various scene modes, white balance adjustment, and basic image editing features directly within the camera.
Power is supplied typically through AA batteries, making it convenient for replacement during field use.
Specifications
| MPN | D-535 ZOOM, 225515 |
| UPC | 0050332149526 |
| Model | D-535 Zoom |
| Digital Zoom | Approx. 2x |
| Battery Type | 4 x AA batteries |
| Features | Date/Time Stamp, DPOF Support, Rgb Primary Color Filter, PictBridge Support, Digital Image Rotation, Print Image Matching |
| Series | Olympus CAMEDIA |
| Optical Zoom | 3x |
| Depth | 1.5in |
| Width | 3.5in |
| Item Weight | 4.9 Oz. |
| Height | 2.5in |
| Screen Details | LCD Display-Tft Active Matrix-1.5"-Color |
| Exposure Compensation | ±2 Ev Range, in 1/3 Ev Steps |
| Light Sensitivity | Iso Auto (64-250) |
| Sensor Type | CCD |
| Max Shutter Speed | 1/2000 Sec |
| Shooting Modes | Frame Movie Mode |
| Macro Focus Range | 2-90cm |
| Focal Length Equivalent to 35mm Camera | 38-114mm |
| White Balance | Auto, Daylight, Cloudy, Fluorescent, Tungsten |
| Focus Adjustment | Automatic |
| Battery Form Factor | Standard Form Factor |
| Operating System Supported | Ms Windows XP, Ms Windows ME, Ms Windows 2000, Ms Windows 98SE, Apple Mac OS X 10.2 or Later |
| Expansion Slot | 1X xD-Picture Card |
| Sensor Size | 1/2.7in |
| Display Size | 1.5in |
| Still Image Format | JPEG |
| Exposure Modes | Program, Automatic |
| Integrated Memory Size | 12MB |
| Display Rotation | Built-In |
| Digital Video Format | Quicktime |
| Screen Size | 1.5in |
| Light Sensitivity Max | 250 |
| Max Operating Temperature | 40°C |
| Type | Point & Shoot |
| Maximum Resolution | 2048 x 1536 pixels |
| Optical Viewfinder Type | Real-Image Zoom |
| Red Eye Reduction | Yes |
| Min Shutter Speed | 2 Sec |
| Floppy Drive Storage | None |
| Display Type | LCD |
| Sensor Resolution | 3.2MP |
| Exposure Metering | Multi-Segment |
| Additional Features | Date/Time Stamp, Dpof Support, Rgb Primary Color Filter, PictBridge Support, Digital Image Rotation, Print Image Matching |
| Flash Type | Built-In Flash |
| Min Operating Temperature | 0°C |
| Effective Flash Range | 0.2m-3.8m |
| Exterior Color | Silver |
| Microphone Type | None |
| Connector Types | 1X Composite Video Output, 1X DC Power Input, 1X USB |
| Shooting Programs | Portrait Mode, Landscape, Self-Portrait, Night Scene |
| Flash Modes | Red-Eye Reduction, Fill-In Mode, Off Mode, Auto Mode |
| Camera Type | Digital Compact Camera |
| Auto Focus Type | TTL Contrast Detection |
| Viewfinder Type | Optical |
| Supported Flash Memory | xD-Picture Card, xD-Picture Card Type H, xD-Picture Card Type M |
| Release Year | 2002 |
| Effective Pixels | 3.2 Megapixels |
| Lens | Fixed Lens, 38-114mm equivalent |
| Aperture | f/2.8 - f/4.8 |
| Shutter Speed Range | 1/4 to 1/600 sec |
| ISO Sensitivity | ISO 80-160 |
| Focus Modes | Auto Focus / Manual Focus |
| Flash | Built-In Flash with Auto, Red-Eye Reduction |
| Viewfinder | Electronic Viewfinder |
| LCD Screen | 1.8-inch TFT Color LCD |
| Storage Media | SmartMedia Card (up to 64MB supported) |
| Interface | USB 1.1 |
| Weight | Approx. 300 g (without batteries) |
| Dimensions | 112 (W) x 65 (H) x 47 (D) mm |
Images
Key Advantages
The Olympus Camedia D-535 Zoom offers a user-friendly compact design ideal for casual photography.
Its 3x optical zoom provides versatility for different shooting situations without degrading image quality.
The 3.2MP sensor produces respectable image resolution for prints and web use.
SmartMedia storage allows easy expansion and compatibility with various card capacities.
Multiple exposure modes and scene presets enhance creative control for the user.
USB connectivity ensures swift and straightforward image downloading to a PC.
Limitations
The 3.2MP resolution is limited by modern standards, affecting print sizes and detail capture.
SmartMedia cards are now obsolete and harder to find compared to modern memory cards.
Battery life may be limited due to the use of AA batteries, which can be less efficient than rechargeable proprietary packs.
The camera lacks advanced features such as video recording or high ISO performance in low light.
The electronic viewfinder is relatively small and low resolution compared to optical or modern digital types.
Slow startup and shot-to-shot times can reduce usability in fast-paced shooting environments.
FAQ
What is the maximum image resolution of the Olympus D-535 Zoom?
The maximum image resolution is 2048 x 1536 pixels, produced by the camera's 3.2-megapixel CCD sensor.
Does the Olympus D-535 Zoom support video recording?
No, this model does not support video recording; it is designed solely for still photography.
What type of memory cards does the Olympus D-535 Zoom use?
It uses SmartMedia cards for image storage.
What kind of batteries power the Olympus D-535 Zoom?
The camera is powered by standard AA batteries.
Is the Olympus D-535 Zoom still available for purchase new?
No, the Olympus D-535 Zoom has been discontinued and is only available on the used market.
What is the optical zoom capability of the camera?
The camera features a 3x optical zoom lens.
Does the camera have a viewfinder?
Yes, it includes an electronic viewfinder as well as an LCD screen for composing shots.
