Canon Eos 20d image

Canon Eos 20d

Quick information
Brand Canon 2004
Model 0206b001, eos 20d
Released Year 2004
Type Digital Cameras
Series Eos
Color Black
Optical Zoom 3x
Status Discontinued
Quick view

Overview

The Canon EOS 20D is a digital single-lens reflex (DSLR) camera introduced in 2004 featuring an 8.2-megapixel APS-C size CMOS sensor. It provides high-resolution image capture with a 1.6x crop factor compared to full-frame sensors, offering enhanced telephoto reach. The camera uses Canon's DIGIC II image processor, enabling rapid processing speeds and improved image quality. It supports a maximum ISO range of 100 to 1600, expandable to 3200, facilitating low-light photography. The EOS 20D's shutter speed ranges from 1/8000 to 30 seconds, including bulb mode for long exposures. For autofocus, it employs a 9-point AF system with one center cross-type sensor, enhancing focusing accuracy and speed.

The camera offers a 2.5-inch LCD screen for image review and menu navigation. It features a compact, robust magnesium alloy body designed for durability and weather resistance. The EOS 20D supports CF memory cards for storage and includes USB 2.0 connectivity for fast data transfer. Its burst shooting mode achieves up to 5 frames per second, suitable for action photography. The camera's flash system includes a built-in pop-up flash and compatibility with external Speedlites. Overall, the EOS 20D combines advanced technology and solid build quality for enthusiast photographers.

Specifications

Digital Zoom 3x
Screen Size 1.8 in
Color Black
MPN 0206B001, CANON EOS 20D
Battery Type Lithium-Ion
Series Canon EOS
Type Digital SLR
Maximum Resolution 8.2 MP
Model Canon EOS 20D
Connectivity USB 2.0
Optical Zoom 3x
Features Auto Focus, Built-in Flash
Country/Region of Manufacture Japan
Item Weight 17.1 Oz.
Camera Type Digital SLR
Sensor Type CMOS
Sensor Size 22.5 x 15.0 mm (APS-C)
Resolution 8.2 megapixels
Image Processor DIGIC II
ISO Sensitivity 100–1600 (expandable to 3200)
Shutter Speed 1/8000 to 30 sec, Bulb
Continuous Shooting 5 fps
Autofocus Points 9 points (1 cross-type center)
Viewfinder Pentaprism, approximately 95% coverage
LCD Screen 2.5 inches TFT LCD
Storage Media CompactFlash (Type I and II)
Flash Built-in pop-up flash; external Speedlite compatible
Battery BP-511A Lithium-ion
Dimensions Approx. 146.7 x 107.5 x 74.4 mm
Weight Approx. 790 g (body only)

Key Advantages

The Canon EOS 20D provides excellent image quality with an 8.2-megapixel CMOS sensor and DIGIC II processor. Its fast continuous shooting speed of 5 fps is ideal for capturing action scenes. The 9-point autofocus system offers accurate and reliable focusing performance. The durable magnesium alloy body enhances its ruggedness and weather resistance for demanding shooting environments. The 2.5-inch LCD facilitates convenient image review and menu operation. Additionally, it supports a broad ISO range, enabling versatility in various lighting conditions.

Limitations

The EOS 20D lacks live view and video recording capabilities present in newer DSLR models. The LCD screen is fixed and does not offer tilt or touch functionality. Its maximum ISO sensitivity of 1600 (expandable to 3200) is limited compared to modern cameras, affecting low-light performance. The 8.2-megapixel resolution is considered low by today's standards. The use of CompactFlash cards limits compatibility with newer storage media. Additionally, the absence of built-in image stabilization requires stabilization either in lenses or external equipment.
