Sigma SD1 MERRILL
| Brand | Sigma 2010 |
| Model | C26900 |
| Released Year | 2010 |
| Type | DSLR Cameras |
| Series | SD1 |
| Color | Black |
| Compatible Mountings | Sigma SA Bayonet |
| Autofocus | Yes |
| Photo Sensor Resolution | 46 MP |
| Video Resolution | FHD 1080p |
| Optical Zoom | 1.5 x |
| File Format | RAW, JPEG |
| Status | Discontinued |
Overview
The Sigma SD1 Merrill is a DSLR camera renowned for its unique Foveon X3 image sensor technology, which captures images with extraordinary color depth by recording red, green, and blue light at every pixel location. Released in 2012, the SD1 Merrill features a 46-megapixel effective resolution sensor, offering exceptional detail and image quality. It operates with a True II image processing engine designed to enhance image clarity and reduce noise. The camera body supports interchangeable lenses compatible with the Sigma SA mount system, providing versatility for photographers. Its robust magnesium alloy frame ensures durability while maintaining a manageable weight. Additionally, the SD1 Merrill includes a 3-inch LCD screen for image review and menu navigation, along with HDMI output for high-definition video display.
Specifications
| Built-In Media | Camera Body Only |
| Are Batteries Included | Yes |
| Remote Included | No |
| Series Number | 26900 |
| Global Trade Identification Number | 00085126928766 |
| UPC | 085126928766 |
| Item Height | 4.45 inches |
| Manufacturer | Sigma Corporation of America |
| Connectivity Technology | USB |
| Wireless Technology | Yes |
| Total USB 2.0 Ports | 1 |
| Total USB Ports | 1 |
| Total Video Out Ports | 1 |
| Shooting Modes | Manual |
| Digital-Still | Yes |
| Movie Mode | Yes |
| Image Capture Type | Stills & Video |
| Night vision | No |
| Auto Focus Technology | Phase Detection, Multi-area, Single, Continuous |
| Focus Features | TTL phase difference detection system |
| Autofocus Points | 11 |
| Focus Type | automatic with manual |
| Focus Mode | Continuous-Servo AF (AF-C) |
| Autofocus | Yes |
| Aspect Ratio | 1.55:1 |
| File Format | RAW, JPEG |
| Effective Still Resolution | 46 MP |
| JPEG Quality Level | Fine |
| Total Still Resolution | 46 MP |
| Maximum Focal Length | 800 Millimeters |
| Optical Zoom | 1.5 x |
| Lens Type | Standard Zoom |
| Zoom | Optical Zoom |
| Camera Lens | Standard Zoom Lens, 4.5-800mm |
| Minimum Focal Length | 4.5 Millimeters |
| Real Angle Of View | 0.83 Degrees |
| Lens Correction Type | Peripheral Illumination |
| Number of Diaphragm Blades | 9 |
| Metering Methods | Multi, Center-weighted, Average |
| Exposure Control | Manual |
| White Balance Settings | Auto |
| Self Timer | 10 seconds |
| Screen Size | 3 Inches |
| Display Type | LCD |
| Dots Per Screen | 495,688 |
| Display Fixture Type | Fixed |
| Display Resolution Maximum | 460,000 |
| Has Color Screen | No |
| Flash Memory Type | Compact Flash (Type I, UDMA compatible) |
| Write Speed | 6 fps |
| Flash Memory Bus Interface Type | PATA |
| Compatible Mountings | Sigma SA Bayonet |
| Sensor Type | CMOS |
| Image stabilization | Digital |
| Maximum Aperture | 1.4 |
| Expanded ISO Minimum | 50 |
| Photo Sensor Resolution | 46 MP |
| Photo Sensor Size | APS-C |
| Maximum Shutter Speed | 30 seconds |
| Minimum Shutter Speed | 1/8000秒~30秒、Bulb(30秒まで:拡張モード時:2分まで) |
| Form Factor | Mid-size SLR |
| Special Feature | Lightweight |
| Color | Black |
| Item Weight | 2 Pounds |
| Video Resolution | FHD 1080p |
| Viewfinder | Optical |
| Flash Modes | Auto, Slow Sync |
| Camera Flash | Built-In |
| Skill Level | Professional |
| Compatible Devices | Sigma SA Bayonet |
| Continuous Shooting | 6 |
| Aperture modes | F1.4 |
| Viewfinder Magnification | 0.95x |
| Flash Sync Speed | 1/180_sec |
| Video Capture Format | MP4 |
| Battery Weight | 77 Grams |
| Delay between shots | 0.17 seconds |
| Battery Cell Type | Lithium Ion |
| Battery Type | Lithium Ion |
| Processor Description | Dual True II |
| Water Resistance Level | Not Water Resistant |
Images
FAQ
What is the key feature of the Sigma SD1 Merrill's sensor?
The Sigma SD1 Merrill uses the unique Foveon X3 sensor that captures full-color information at every pixel, providing high color accuracy and resolution.
Is the Sigma SD1 Merrill compatible with other lenses?
Yes, it supports lenses with the Sigma SA mount.
What image quality can I expect from the SD1 Merrill?
The camera delivers very high-resolution images with 46 megapixels effective resolution and excellent color fidelity.
Does the Sigma SD1 Merrill support video recording?
No, the Sigma SD1 Merrill primarily focuses on still photography and does not offer video recording capabilities.
Is the Sigma SD1 Merrill still produced today?
No, the Sigma SD1 Merrill has been discontinued.
What type of image processor does the Sigma SD1 Merrill use?
It uses the True II image processing engine to improve clarity and reduce noise.
What are the main body features of the Sigma SD1 Merrill?
The camera features a durable magnesium alloy body and a 3-inch LCD screen for image review.
